Introduction
GS-LS-E Integrated Digital Marine Lantern is specially designed for special area such as sea, river way,lakes. Adopts special customized LED chip, which has the specific of high light intensity, low power consumption,long service life.Lampshade adopts PC material, which can corrosion resistance, anti-UV anti-shock. The base adopts marine-grade dedicated plastic material,it can apply to seaways and chemical plant that have hostile and strong corrosive environment.
Name |
Parameter |
Name |
Parameter |
Type |
GS-LS/E |
Light Source Life |
＞100000 hours |
Power Provider |
Mono-crystalline silicon solar panel |
Optional Emitting Light Colors |
Red, Amber Yellow, Green, Blue, White |
Battery Capacity |
3.2V3.3AH |
Battery Type |
Replaceable lithium iron phosphate battery |
Battery lifespan |
＞5years |
Solar panel voltage |
5.5V |
Solar panel Power Consumption |
2W |
Solar panel lifespan |
＞20years |
Power Consumption |
≤2W |
Vertical Divergence |
＞10° |
Visual Range |
1~4 NM |
Horizontal Out-put |
360° |
LED Quantity |
20pcs |
Overall Size(mm) |
186mm(D)x190mm(H) |
Light Source |
LED |
Installation Size(mm) |
D170mm x M6 |
Working temperature |
-40℃~70℃ |
Wind-speed Ability |
80m/s |
Storage temperature |
-40℃～70℃ |
Working mode |
Flashing(20tims/min) |
Sun Switch Illumination Threshold |
300LUX±100LUX |
Steady Burning Intensity |
32.5cd |
Continuous Burning Time in rainy days |
＞20 days (12 hours a day) |
Flashing Intensity |
33cd |
Weight |
1.2kg |
IP Protection |
IP65 |
Function&Features
l Photocell can switch ON/OFF the light in rainy days or at night automatically.
l Standardization of optical design, high photoelectric conversion efficiency.
l The integration of the waterproof design, it can work in soaking in sea water, High protection grade IP68.
l Adopts special customized LED chip,transfer efficiency and service life is higher than normal LED.
l The lamp extend state switch, it can adjust steady or flashing light working mode base on requirement.
l Provides strong corrosion resistance, UV resistance, impact resistance.
l Adopts marine-grade dedicated plastic material,it can apply to seaways and chemical plant that have hostile and strong corrosive environment..
l With bird needle to prevent bird drop.
l No radio frequency (rf), no electromagnetic interference
l Steady working, low cost.
Application
l Sea ways
l River way,
l Lakes
l Mariculture zone
l Block
l Bridge
l Towersr
l Chimney
l Airport runway
l Heliport
l Traffic barrier
l Tower cranes
