UL galvanized steel IMC conduit pipe with China products
| UL galvanized steel IMC conduit pipe with China products | ||||||||
| ANSI C80.3-1983 UL797 | ||||||||
| Size | Outside Diameter | Inside Diameter | Wall Thickness | Length | ||||
| inch | inch | mm | inch | mm | inch | mm | inch | mm |
| 1/2" | 0.815 | 20.7 | 0.810 | 20.6 | 0.070 | 0.85 | 9"-11-1/4" | 3029.0 |
| 3/4" | 1.209 | 26.1 | 1.024 | 26.0 | 0.075 | 0.95 | 9"-11-1/4" | 3029.0 |
| 1" | 1.290 | 32.8 | 1.285 | 32.6 | 0.085 | 1.10 | 9"-11" | 3022.6 |
| 1-1/4" | 1.638 | 41.6 | 1.630 | 41.4 | 0.085 | 1.30 | 9"-11" | 3022.6 |
| 1-1/2" | 1.883 | 47.8 | 1.875 | 47.6 | 0.090 | 1.30 | 9"-11" | 3022.6 |
| 2" | 2.360 | 59.9 | 2.352 | 59.7 | 0.095 | 1.40 | 9"-11" | 3022.6 |
| 2-1/2" | 2.857 | 72.6 | 2.847 | 72.3 | 0.140 | - | 9"-10-1/2" | 3009.9 |
| 3" | 3.476 | 88.3 | 3.466 | 88.0 | 0.140 | - | 9"-10-1/2" | 3009.9 |
| 3-1/2" | 3.971 | 100.9 | 3.961 | 100.6 | 0.140 | - | 9"-10-1/4" | 3003.6 |
| 4" | 4.466 | 113.3 | 4.456 | 113.2 | 0.140 | - | 9"-10-1/4" | 3003.6 |
UL galvanized steel IMC conduit pipe with China products:
Safe product.
Size: From 1/2" to 4".
It's threaded on both ends, circular cross-section, for protecting cables and wires.
It's manufactured in accordance with UL1242 / ANSI C80.6.
Good raw material.
Good weld line.
Clean end of the conduit.
Professional inspection process.
Good performance during wariety tests.
Surface treatment is smooth,have good resistant to corrosion,and all information available at the time of order,if you need different thinkness or lenth please contact us.
Note:Please comply with the national and local building and electrical code requirements when choosing the correct conduit and accessories for your wiring application.
|
|
|
|
|
Q1:When can I get the quotation?
A1:Usually within 24 hours. If urgent please call us .
Q2:Samples can be free?
A2:Yes,we can supply the EMT conduit pipe free of charge just need your detailed courier address enough.
Q3:How about the lead time?
A3:Usually 20 days after deposit in our account.
Q4:Where the loading port and what terms of delivery you acceptable?
A4:Ningbo port and Shanghai port China as our nearest loading port.
EXW, ,FOB,CFR,CIF we acceptable.
Q5:How about your quality and do you have some certifications?
A5:All our products meet the standard of UL,and now we apply the UL certificate this month,soon can get the certification and show to our customers.
If there is a chance come to China please feel free to visit our factory for quality checking and business cooperation.
