Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube > ASTM A213 T91 Seamless Alloy Tube
ASTM A213 T91 Seamless Alloy Tube
US$ 1000 - 6000
MOQ: 10 Tons
Key Specifications
Get Latest Price
Place of Origin:
China
Certification:
BSI
Thickness:
10, 30
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
30 days
Related Products
-
ASTM A213 T22 Seamless Alloy PipeUS$ 1000 - 6000MOQ: 10 Tons -
ASTM A213 T21 Seamless Alloy TubeUS$ 1000 - 6000MOQ: 10 Tons
-
ASTM A213 T11 Seamless Boiler TubeUS$ 1000 - 6000MOQ: 10 Tons
-
ASTM A213 T5b Seamless Alloy TubeUS$ 1000 - 6000MOQ: 10 Tons
-
ASTM A213 T5 Superheater and Heat-Exchanger TubesUS$ 1000 - 6000MOQ: 10 Tons
Place of Origin
China
Certification
BSI
Thickness
10, 30
Application
Hydraulic Pipe
Technique
Cold Drawn
Alloy Or Not
Is Alloy
Secondary Or Not
Non-secondary
Special Pipe
Thick Wall Pipe
Section Shape
Round
Outer Diameter
60, 300
ASTM A213 Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes
ASTM A213M-09 standard is issued under the fixed designation A 213/A 213M; the number immediately following the designation indicates the year of original adoption or, in the case of revision, the year of last revision.
ASTM A213 T91 Seamless alloy tube
alloy steel, ASTM A213, ASTM A213 T91, Seamless alloy tube, steel tubes, superheater tubes, t91, Tubing
ASTM A213 T91 Standard covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes.
Grades containing the letter H in their designation have requirements different from those of similar grades not containing the letter H.
These different requirements provide higher creep-rupture strength than normally achievable in similar grades without these different requirements. ASTM A213 T91 tubes shall be made by the seamless process and shall be either hot finished or cold finished, as specified. Grade TP347HFG shall be cold finished. Heat treatment shall be done separately and in addition to heating for hot forming. The ferritic alloy and ferritic stainless steels shall be reheated. On the other hand, austenitic stainless steel tubes shall be furnished in the heat-treated condition. Alternatively, immediately after hot forming, while the temperature of the tubes is not less than the minimum solution temperature, tubes may be individually quenched in water or rapidly cooled by other means. Tension test, hardness test, flattening test, and flaring test shall be done to each tube. Also, each tube shall be subjected to the nondestructive electric test or hydrostatic test.
ASTM A209 Through A213
Other standard specifications include the categories of A209 seamless carbon-molybdenum alloy-steel boiler and superheater tubes; A210 seamless medium-carbon steel boiler and superheater tubes and A213 seamless ferritic and austenitic steel boiler, superheater and heat-exchanger tubes. Piping wall thicknesses range from 1/2 inch to 5 inches. A213 grades also have the letter H or M assigned, which changes the composition and specifications for that series.
This abstract is a brief summary of the referenced standard. It is informational only and not an official part of the standard; the full text of the standard itself must be referred to for its use and application. ASTM does not give any warranty express or implied or make any representation that the contents of this abstract are accurate, complete or up to date.
Chemical Composition(%) for ASTM A213 T91 Low Alloy Steel
Mechanical properties for ASTM A213 T91 Low Alloy Steel
Permitted tolerance for OD
Wall thickness is average wall or according to ASME SA530.
