Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Pipe & Tube > ASTM A335 P11 Alloy Steel Pipe

ASTM A335 P11 Alloy Steel Pipe

ASTM A335 P11 Alloy Steel Pipe thumbnail-3

ASTM A335 P11 Alloy Steel Pipe thumbnail-4

US$ 1000 - 6000 MOQ: 10 Tons

Key Specifications

Get Latest Price

Place of Origin:

China

Certification:

BSI

Thickness:

10, 30

Contact Supplier Request Quote Chat Now

Sunny Steel Pipe Manufactory

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

30 days

Product Details
Company Profile
Contact Us

Place of Origin China

Certification BSI

Thickness 10, 30

Application Hydraulic Pipe

Technique Cold Drawn

Alloy Or Not Is Alloy

Secondary Or Not Non-secondary

Special Pipe Thick Wall Pipe

Section Shape Round

Outer Diameter 60, 300

a335, alloy steel, ASTM A335, ASTM A335 P11, ASTM A335 pipe, p11

ASTM A335 P11 is the part of ASTM A335, the pipe shall be suitable for bending, flanging, and similar forming operations, and for fusion welding. The steel material shall conform to chemical composition, tensile property, and hardness requirements. Each length of pipe shall be subjected to the hydrostatic test. Also, each pipe shall be examined by a non-destructive examination method in accordance to the required practices.

The different mechanical test requirements for pipes, namely, transverse or longitudinal tension test, flattening test, and hardness or bend test are presented.Both ends of each crate will indicate the order no., heat no., dimensions, weight and bundles or as requested.

Material & Manufacture

Pipe may be either hot finished or cold drawn with the finishing heat treatment noted below.

Heat Treatment

A / N+T
N+T / Q+T
N+T

Mechanical Tests Specified

Transverse or Longitudinal Tension Test and Flattening Test, Hardness Test, or Bend Test
For material heat treated in a batch-type furnace, tests shall be made on 5% of the pipe from each treated lot. For small lots, at least one pipe shall be tested.
For material heat treated by the continuous process, tests shall be made on a sufficient number of pipe to constitute 5% of the lot, but in no case less than 2 pipe.

Notes for Hardness Test:

P11 shall not have a hardness not exceeding 250 HB/265 HV [25HRC].

Notes for Bend Test:

For pipe whose diameter exceeds NPS 25 and whose diameter to wall thickness ratio is 7.0 or less shall be subjected to the bend test instead of the flattening test.
Other pipe whose diameter equals or exceeds NPS 10 may be given the bend test in place of the flattening test subject to the approval of the purchaser.
The bend test specimens shall be bent at room temperature through 180 without cracking on the outside of the bent portion.

Chemical Requirements of ASTM A335 P11

Chemical elements	Data
UNS Designa-tion	K11597
Carbon	0.05-0.15
Manganese	0.30-0.60
P&S(max)	0.025
Silicon	0.50-1.00
Chromium	1.00-1.50
Molybdenum	0.44-0.65
Others	—

Mechanical Properties  of ASTM A335 P11

Properties	Data
Tensile strength, min, (MPa)	415
Yield strength, min, (MPa)	205
Elongation, min, (%), L/T	30/20

Packaging

ASTM A335 Grade P22 Alloy Steel Seamless Pipes are bundled as standard, with steel straps into hexagonal bundles with one end flush.Length sorting can be carried out on request. Tubes can also be bundled in multiples. Bundle weights are adjusted as requested by the customer. Each bundle contains tubes from a single cast/heat only.

Marking

ASTM A335 Grade P22 Alloy Steel Seamless Pipes is marked with tube type, heat number, steel grade and size. Information is repeated along the whole length of the tube. Other markings, such as stamping, can be made on request. Bundles are also labeled with a tag having info both alphanumeric and by bar code.

Product Tags: ASTM A335 Grade P22 , Alloy Steel Seamless Pipes , ASTM A335 P11
