Home > Industrial Equipment & Components > Compressor > Compressor Unit > Screw Vacuum Pump

Screw Vacuum Pump

Name: Screw Vacuum Pump
Brand: SUCCESS ENGINE
SKU: 154599652
Availability: InStock

US$ 2000 - 10000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

SUCCESS ENGINE

Place of Origin:

China

Model Number:

SEV5A-SEV90A

Contact Supplier Request Quote Chat Now

Shanghai Success Engine Compressor Co.,Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Any China Port

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name SUCCESS ENGINE

Place of Origin China

Model Number SEV5A-SEV90A

Certification CE, CQC, ASME, UL, CCS

Type Turbo

After-sales Service Provided Engineers available to service machinery overseas

Warranty 1 Year

Condition New

Voltage AC Power 380V/3P/50HZ, can be customied.

Lubrication Style Lubricated

Power Source AC Power

Configuration Stationary

SUCCESS ENGINE Energy Saving Screw Vacuum Pump -Save money, trouble and space! Screw vacuum pumps are widely used in electronics, printing and dyeing, foam, iron & paper printing, machining, photoelectric paper-plastic, blister packaging and other fields. It adopts frequency conversion intelligent control technology to realize automatic adjustment of flow and vacuum pressure according to process demand changes and reduce energy consumption. It is the preferred equipment for investment and energy-saving transformation of small and medium-sized vacuum system projects. For large vacuum system, please visit the introduction of centrifugal vacuum pump.

Screw Vacuum Pump --- Energy-saving, intelligent, high efficiency, save money, trouble and space Screw vacuum pump is small vacuum system, with flow of 5~85m3/ Min, vacuum degree: -60 ~ -100kpa (g).they are mainly used in electronics, printing and dyeing, foam, iron & paper printing, machining, photoelectric paper-plastic, blister packaging and other fields. For large vacuum system, please visit the introduction of centrifugal vacuum pump It adopts frequency conversion intelligent control technology to realize automatic adjustment of flow and vacuum pressure according to process demand changes and reduce energy consumption. It is the preferred equipment for investment and energy-saving transformation of small and medium-sized vacuum system projects. Fully enclosed complete structure - all parts are installed in one cabinet, silencer and anti-vibration facilities are installed. It doesn’t need foundation, and it can be used after connecting the vacuum system pipe the power supply. It can be customized according to the vacuum system parameters required by users, without special requirements, a single vacuum pump can be selected. The complete set of solutions can be configured with stainless steel or carbon steel internal coating separation tank, vacuum buffer tank, magnetic flap level gauge, automatic drainage controller, negative pump, cutting fluid storage tank, valves, pipe fittings and other system requirement. Our goal is to become a leader in the research and development of large and small vacuum technologies, a provider of vacuum energy-saving solutions.

Energy Saving Concept According to the investigation, the cost of traditional vacuum pump includes 3 items during its whole life. Purchase Cost About 15% Maintenance Cost About 10% Energy Consumption (electricity) About 75% According to above data, the energy consumption cost accounts for the majority of the total cost. If energy-saving products are applied, the profits will be greatly improved.

Screw Vacuum Pump and Water Ring Vacuum Pump Save money, trouble and space! Save money: Compared with water ring vacuum pump or roots vacuum pump, it can save at least 160,000 kWh of electricity every year. If the electricity price is calculated at 0.7 yuan per kWh, it can save about 110,000 yuan in electricity costs and increase the flow rate by 12%, while reducing maintenance costs. Save trouble: Avoid the trouble of waste water and noise treatment, worry-free and trouble-free! The most reasonable vacuum point design can be selected according to the operating conditions to make the production process more reasonable and efficient. Save space: All components are installed in a cabinet, no need the foundation, cover a small area and saves site space, especially in buildings and industrial areas.


Strict Rotor Dynamic Balance Test Using advanced dynamic balancing equipment, according to the requirements of "Success Engine Dynamic Balance Test Procedure", a strict dynamic balance test is carried out on each rotor to ensure the rotor balance accuracy level, ensure the balance and stability during full-speed operation, and improve the overall performance of the compressor.


Strict Accuracy Inspection and Hydraulic Test of Compressor Components The three-coordinate measuring instrument is used to carry out strict precision inspection on the compressor airend casing, end cover and other components, and the pressure-bearing components are subjected to a 30 minutes hydraulic test of 1.25 times the design pressure. Only those products that meet the inspection standards and technical requirements can be judged as qualified products.


High Efficiency Centrifugal Cooling System (Patent number: CN201320374179.8) The aerodynamic calculation and full three-dimensional flow simulation are carried out, combined with actual operation data to optimize the volute structure and fan blade profile, to save power, increase dynamic pressure, and achieve the best fan efficiency. Adopts side-entry & top-discharge closed frequency conversion fan cooling structure. Equip with centrifugal fan, the frequency conversion automatically adjusts the fan speed according to the system temperature change.		High Efficient Water Cooling System For high-power unit, unique shell-and-tube baffle and tube-column was designed and installed, effectively improves the heat exchange rate between compressed air and water, and reduces the water consumption. For low-power unit, the plate corrugated superimposed structure can be selected, so that the fluid can form turbulent flow, size is small but with good heat dissipation effect.


High-efficiency Electric Motor Use special high output efficiency motor with high-quality bearings according to the site power supply and process conditions, and available for different voltage, frequency, protection level, insulation level, service factor, VFD, explosion-proof and other required types.


Exquisite Vacuum System Design the optimization design of the layout and connection seal of the screw vacuum pump pipeline system is related to the durable operation of the equipment and the loss of vacuum pressure. Shen Xingjian pays special attention to the sealing effect and pressure difference value of each link in the working system. The sealing components such as the inlet and outlet before and after the separation of oil and gas are specially optimized to ensure the sealing and durability of the system.


Screw Vacuum Pump Rotors


Efficient Oil & Air Separation Device and Lubricating Medium


Ingenious Design, Reliable as it Seems


Intelligent Control (Standard Configuration)


Frequency Conversion Control / Soft Start Control (Selective Configuration) Low-voltage unit: built-in structure, with optional of VFD control and dual-purpose controls (Standard + VFD). High-voltage unit: divided structure, separated external high-voltage frequency conversion cabinet. Compressor atomically adjusts the frequency and speed according to the actual air consumption change to achieve effective energy savings, also with the characteristics of stable air pressure, startup without impact.


Energy Efficiency Test (Factory inspection, praise for Grade-1 energy efficiency) SUCCESS ENGINE has its own energy efficiency lab. Each air compressor has undergone strict full performance testing, only when it meets the requirements of various indicators, can be labeled as qualified. Perfect optimization of the SUCCESS ENGINE energy-saving air compressor system is a model for improving the two major needs of "energy-efficiency ratio" and "quality reliability" in the field of civil energy and power, leading the new generation of gas source power.


Ethernet Central Control System (Selective Configuration) The centralized compressor control system communicates with the monitoring station through the industrial Ethernet ring network, performs remote monitoring and intelligent control of the equipment in the air compressor room, and realizes automatic unattended operation. Configuration: linkage control PLC system, control cabinet, UPS, wireless communication equipment, video monitoring system, voice broadcasting system, computer operation station, display, printer, work table.


Loading and Delivering


Typical Air Compressor Station


User Installation Scenarios


Factory Assembly Area
