25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1

25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 thumbnail-1
25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 thumbnail-2
25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 thumbnail-3
25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 photo-1
25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 photo-2
25W 350/500/700mA 1 Channel 1-10v Constant Current Dimmable Led Driver EUP25A-1WMC-1 photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
EUCHIPS / OEM / ODM
Place of Origin:
China
Model Number:
EUP25A-1WMC-1
Contact Supplier Request Quote Chat Now
Shanghai Euchips Industrical CO.,LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name EUCHIPS / OEM / ODM
Place of Origin China
Model Number EUP25A-1WMC-1

Feature
1. Output current level selectable by DIP S.W.
2. Wide range of input voltage 100VAC ~ 240VAC
3. High efficiency up to 86%
4. Built-in active PFC function
5. Protections: Short circuit
6. Class II power unit, no FG
7. Suitable for indoor LED lighting application
Technical Parameter
Product Name: 25W 350/500/700mA 1 channel 1-10v constant current dimmable led driver
Item: EUP25A-1WMC-1
Output Current: 350/500/700mA
Channels: 1 channel
Current Accuracy: ±3%
R & N (Max): 30mA p-p
Frequency Range: 47~63Hz
Power Factor(Type): PF≧0.9/240VAC at rated power
Efficiency(Type): 86%
Input Current: 0.12A@240VAC
Leakage Current:<0.5mA/240VAC
Inrush current(Type): COLD START 1.2A at 240VAC
Short Circuit: Constant current limiting, recovers automatically after removed
Dimming: 1-10V dimming
More information at www.euchips.com & www.euchips.net
