980nm Laser Diode K98S02F-10.00W-R

Specifications（25℃）

Symbol

Unit

K91S02F-10.00W-R

K94S02F-10.00W-R

K98S02F-10.00W-R

Optical data

CW-output power

Po

W

10

Center wavelength

lc

nm

915

940

976

Tolerance of l

-

nm

±3, ±10

Spectral width (FWHM)

△l

nm

<5

Temperature drift of l

-

nm/℃

~0.3

Fiber data

Fiber core diameter

Wc

µm

105

Numerical aperture

NA

-

0.15/0.22

Fiber connector

-

-

FC, ST, SMA-905

Electrical data

Operation current

Iop

A

12

Threshold current

Ith

A

0.5

Conversion efficiency

η

%

46

Slope efficiency

ηD

W/A

0.9

Operation voltage

Vop

V

1.9

Reverse voltage

Vre

V

2.5

Feedback

Isolation

Wavelength range

l

nm

1040-1100

Isolation

-

dB

>45

Other specifications

Operation temperature

Top

℃

10~30

Storage temperature

Tst

℃

-20~+80

Expected lifetime

MTBF

h
