Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Two Color Injection Molding Machine DKM260D Dakumar-m
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Dakumar
Place of Origin:
China
Model Number:
DKM260D
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Two Color Injection Molding Machine DKM200D Dakumar-mNegotiableMOQ: 1 Set -
Bi-Injection Molding Machine DKM140D Dakumar-mNegotiableMOQ: 1 Set
-
Two Color Injection Molding Machine DKM1000D Dakumar-mNegotiableMOQ: 1 Set
-
Two Color Injection Molding Machine DKM450D Dakumar-mNegotiableMOQ: 1 Set
-
Mix-Colour Injection Molding Machine DKM188D Dakumar-mNegotiableMOQ: 1 Set
Brand Name
Dakumar
Place of Origin
China
Model Number
DKM260D
Two Color Injection Molding Machine DKM260D
DKM260D PLATEN DIMENSION Dakumar Injection Molding Machine DKM260D Parameters Items Unit DKM260D Injection Unit Screw Type A B Screw Diameter mm 32 36 40 45 Injection Pressure kgf/ 2530 1997 1618 1300 Theoretical Shot Volume c 128 162 200 2
If you want to get more details about our molding machine,please mail to
If you want to get more details about our molding machine,please mail to
martet02@sinogroupe.com or visit :/en/DKM260D-Double-Color-Injection-Machine.html
Two Color Injection Molding Machine DKM260D
PLATEN DIMENSION
|
Dakumar Injection Molding Machine DKM260D Parameters
|
||||||||
| Items | Unit |
DKM260D
|
||||||
| Injection Unit |
Screw Type |
|
||||||
| Screw Diameter | mm |
32
|
36
|
40
|
45
|
|||
| Injection Pressure | kgf/ |
2530
|
1997
|
1618
|
1300
|
|||
| Theoretical Shot Volume | c |
128
|
162
|
200
|
253
|
|||
| Shot Weight Of Injection | gram |
117
|
148
|
186
|
232
|
|||
| ozs |
4.1
|
5.2
|
6.5
|
8.1
|
||||
| Injection Rate | c /sec |
80
|
101
|
125
|
158
|
|||
| Plasticizing Capacity(PS) | kg/hr |
27.5
|
34.8
|
43
|
54
|
|||
| Screw Rotation Speed | rpm |
150
|
||||||
| Clamping Unit | Mould Clamping Force | metric ton |
260
|
|||||
| Mould Clamping Stroke | mm |
400
|
||||||
| Mould Thickness | mm |
200-500
|
||||||
| Distance Between Tie Bar (HxV) | mm |
1190x685
|
||||||
| Mould Platen(HxV) | mm |
1450x930
|
||||||
| Ejector Stroke | mm |
110
|
||||||
| Rotary Table Diameter | mm |
980
|
||||||
| Distance Between Barrel Centers | mm |
500
|
||||||
| Min Distance Between Molds | mm |
80
|
||||||
| Mold Sets | set |
2
|
||||||
| Electrical Equipment | Pumo Driving Motor | hp(kw) |
40(29.84)
|
|||||
| Temperature Controller | set |
2-(0-400 )x4
|
||||||
| Heater Capacity | kw |
8x2
|
||||||
| Others | Machine Dimensions(lxWxH) | mm |
6500x1750x2100
|
|||||
| Oil Tank Capacity | liter |
800
|
||||||
| Machine Weight | metric ton |
17
|
||||||
| Max.System Pressure | kgf/c |
140
|
||||||
