Two Color Injection Molding Machine DKM450D Dakumar-m
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
dakumar
Place of Origin:
China
Model Number:
DKM450D
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Two Color Injection Molding Machine DKM260D Dakumar-mNegotiableMOQ: 1 Set -
Two Color Injection Molding Machine DKM200D Dakumar-mNegotiableMOQ: 1 Set
-
Bi-Injection Molding Machine DKM140D Dakumar-mNegotiableMOQ: 1 Set
-
Two Color Injection Molding Machine DKM1000D Dakumar-mNegotiableMOQ: 1 Set
-
Standard Injection Machine-dakumar-mNegotiableMOQ: 1 Set
Brand Name
dakumar
Place of Origin
China
Model Number
DKM450D
Two Color Injection Molding Machine DKM450D
DKM450D PLATEN DIMENSION dakumar Injection Molding Machine DKM450D Parameters Items Unit DKM450D Injection Unit Screw Type A B Screw Diameter mm 50 50 Injection Pressure kgf/ 2048 2048 Theoretical Shot Volume cm 3 534 534 Shot Weight Of Inj
If you want to get more details about our molding machine,please mail to
DKM450D PLATEN DIMENSION dakumar Injection Molding Machine DKM450D Parameters Items Unit DKM450D Injection Unit Screw Type A B Screw Diameter mm 50 50 Injection Pressure kgf/ 2048 2048 Theoretical Shot Volume cm 3 534 534 Shot Weight Of Inj
If you want to get more details about our molding machine,please mail to
martet02@sinogroupe.com or visit :/en/DKM450D-Double-Color-Injection-Machine.html
Two Color Injection Molding Machine DKM450D
PLATEN DIMENSION
|
dakumar Injection Molding Machine DKM450D Parameters
|
||||||
| Items | Unit |
DKM450D
|
||||
| Injection Unit |
Screw Type |
|
||||
| Screw Diameter | mm |
50
|
50
|
|||
| Injection Pressure | kgf/ |
2048
|
2048
|
|||
| Theoretical Shot Volume | cm3 |
534
|
534
|
|||
| Shot Weight Of Injection | gram |
491
|
491
|
|||
| ozs |
17.3
|
17.3
|
||||
| Injection Rate | c /sec |
205
|
205
|
|||
| Plasticizing Capacity(PS) | kg/hr |
160
|
160
|
|||
| Screw Rotation Speed | rpm |
100
|
||||
| Clamping Unit | Mould Clamping Force | metric ton |
450
|
|||
| Mould Clamping Stroke | mm |
600
|
||||
| Mould Thickness | mm |
200-600
|
||||
| Distance Between Tie Bar (HxV) | mm |
1100x610
|
||||
| Mould Platen(HxV) | mm |
1450x930
|
||||
| Ejector Stroke | mm |
110
|
||||
| Rotary Table Diameter | mm |
1200
|
||||
| Distance Between Barrel Centers | mm |
550
|
||||
| Min Distance Between Molds | mm |
80
|
||||
| Mold Sets | set |
2
|
||||
| Electrical Equipment | Pumo Driving Motor | hp(kw) |
2x40(59.7)
|
|||
| Temperature Controller | set |
2-(0-400)x5
|
||||
| Heater Capacity | kw |
13x2
|
||||
| Others | Machine Dimensions(lxWxH) | mm |
7500x2000x2100
|
|||
| Oil Tank Capacity | liter |
1500
|
||||
| Machine Weight | metric ton |
20
|
||||
| Max.System Pressure | kgf/c |
140
|
||||
