High Speed Injection Machine DKM268HS Dakumar-m
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Dakumar
Place of Origin:
China
Model Number:
DKM268HS
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
High Speed Injection Machine DKM188HS Dakumar-mNegotiableMOQ: 1 Set -
High Speed Injection Machine DKM218HS Dakumar-mNegotiableMOQ: 1 Set
-
Two Color Injection Molding Machine DKM260D Dakumar-mNegotiableMOQ: 1 Set
-
Two Color Injection Molding Machine DKM200D Dakumar-mNegotiableMOQ: 1 Set
-
Bi-Injection Molding Machine DKM140D Dakumar-mNegotiableMOQ: 1 Set
Brand Name
Dakumar
Place of Origin
China
Model Number
DKM268HS
DKM268HS High Speed Injection Machine
DKM268HS PLATEN DIMENSION DKM268HS dakumar Injection Molding Machine DKM268HS Parameters A B C Injection Unit Screw Diameter mm 50 55 60 Screw L/D Ratio L/D 22.2 20.1 18.5 Shot Volume cm 3 570 688 819 Injection Weight(PS)
DKM268HS High Speed Injection Machine
PLATEN DIMENSION
| DKM268HS | ||||||
| dakumar Injection Molding Machine DKM268HS Parameters | A | B | C | |||
| Injection Unit | Screw Diameter | mm | 50 | 55 | 60 | |
| Screw L/D Ratio | L/D | 22.2 | 20.1 | 18.5 | ||
| Shot Volume | cm3 | 570 | 688 | 819 | ||
| Injection Weight(PS) | g | 518 | 630 | 746 | ||
| Injection Pressure | mpa | 204 | 169 | 143 | ||
| Injection Rate | cm3/s | 228.7 | 276.7 | 329.3 | ||
| Injection Speed | mm/s | 128 | ||||
| Screw Speed | rpm | 0-170 | ||||
| Clamping Unit | Clamp Tonnage | kn | 2680 | |||
| Toggle Stroke | mm | 545 | ||||
| Space Between Tie-Bars | mm | 570x570 | ||||
| Max. Mold Height | mm | 570 | ||||
| Min. Mold Height | mm | 230 | ||||
| Ejector Stroke | mm | 130 | ||||
| Ejector Tonnage | kn | 62 | ||||
| Ejector Number | piece | 9 | ||||
| Others | Max. Pump Pressure | mpa | 16 | |||
| Motor Power | kw | 30 | ||||
| Heater Power | kw | 16.15 | ||||
| Machine Dimension | m | 6.2x1.45x2.2 | ||||
| Machine Weight | ton | 9 | ||||
| Oil Tank Capacity | L | 500 | ||||
