GD-4508G Bitumen Ductility Tester

GD-4508G Bitumen Ductility Tester thumbnail-1
GD-4508G Bitumen Ductility Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-4508G
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-4508G

Introduction:

The instrument is designed and made as per national standard GB/T 4508-2010 Standard Test Method for Ductility of Bitumen and T0605-2011 Asphalt Ductility Test in JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering of People’s Republic of China. The method is applied to the GB/T 4508-2010 and T0605-2011 standards. Determination of petroleum asphalt under the predetermined conditions and in certain temperature, at a certain speed stretch to fracture length, called petroleum asphalt ductility, expressed in cm. And two samples of it can be used to do the tensile strength test.

I. Features:

1.  It adopts humanized design philosophy. There is no leading screw, lead rail or other components in the test trough. It adopts innovative transmission design. The stretching is stable and synchronous. There is no tremble and the speed is uniform. The sample can be easily installed in and the maximum measurement distance can reach 1.5m.

2. It can determine ductility of three samples and tensile forces of two samples by one analysis.

3.   It adopts PC control technology. The temperature control accuracy is high. It has the function of automatic specimen positioning. The ductility determination can be operated remotely. Equipped with a communication port, it achieves the communication with PC conveniently.

4. It adopts large LCD to show the temperature, ductility, tensile force clearly.

5.  It equips a needle micro-printer to printer out the test results automatically (Ductility, average value, maximum tensile force and the changing curves).

6.  The specimen can return and positioning automatically after the determination.


II. Specifications:

Power supply AC（220±10%）V、50Hz
Measurement distance 1.5m（±10mm）
Heating power 3200W
Temperature control Range：(5～35)℃, accuracy： ±0.1℃
Tensile speed (10～50)mm/min, stepless adjustment. accuracy：±1mm
Tensile test Range：(0～300)N, accuracy：±1N, resolution：0.1N
Data output （1）Communication port RS232
（2）Printed by micro-printer
Refrigeration Compressor 1.0P, input power is 800W

Ambient temperature (-10～+35)℃。
Relative humidity  ≤85%
Maximum power consumption 4100W
Overall dimension 2365mm×530mm×1000mm
Product Tags: Asphalt ductility tester , Ductility tester , Asphalt Testing Equipment
