GD-2806F Softening Point Tester

GD-2806F Softening Point Tester thumbnail-1
GD-2806F Softening Point Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-2806F
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-2806F

Introduction:

 The instrument is designed and made as per national standard GB/T 4508-2010 Standard Test Method for Ductility of Bitumen and T0605-2011 Asphalt Ductility Test in JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering of People’s Republic of China. The method is applied to the GB/T 4508-2010 and T0605-2011 standards. Determination of petroleum asphalt under the predetermined conditions and in certain temperature, at a certain speed stretch to fracture length, called petroleum asphalt ductility, expressed in cm.

Introduction:

The instrument is designed and made as per GB/T4507 Standard Test Methods for Softening Point of Petroleum Asphalt of National Standard of People’s Republic of China , T0608 Asphalt Softening Point Test (Ring-and-Ball Apparatus) in the industrial standard of People’s Republic of China JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering. It is suitable to determine softening point of petroleum asphalt, coal pitch, liquid petroleum asphalt, and various asphalts. It can be widely used for asphalt manufacturing companies, highway and bridge construction companies, relative colleges and universities, and scientific research institutes.

I. Features:

1.   Small desktop structure. Controlled by micro-computer. Linear heating and automatic stir. It shows the reliable test result.

2.  The beaker is made of high-temperature resistant glass. The rings and balls all meet requirements of standard test methods.

3.  An automatic stirrer is equipped in the bath. LED shows time and temperature. It can test two samples at a time. Easy to use.


II. Specifications:

Power supply AC 220V±10%, 50 Hz
Environment The room temperature should be lower than 35 ℃ and keep stable without air convection
Measurement range 32℃～150 ℃; ±1.0 ℃
Stirrer The stirring speed can be continuously adjusted.
Heating power 800 W
Heating medium glycerin
Beaker cubage 1000 ml
Relative humidity ≤ 85%
Total power consumption ≤ 850 W
Test sample 2 samples

Product Tags: Softening Point Tester , Asphalt softening point tester , Asphalt Testing Equipment
