GD-4508C Bitumen Ductility Tester

GD-4508C Bitumen Ductility Tester thumbnail-1
GD-4508C Bitumen Ductility Tester photo-1
US$ 1 - 1 MOQ: 1 Bag
Key Specifications
Get Latest Price
Brand Name:
GOLD
Place of Origin:
China
Model Number:
GD-4508C
Contact Supplier Request Quote Chat Now
Chongqing Gold Mech
Payment & Shipping
Payment Methods:
Port of Shipment:
Chongqing
Delivery Detail:
15 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name GOLD
Place of Origin China
Model Number GD-4508C

Introduction:

 The instrument is designed and made as per national standard GB/T 4508-2010 Standard Test Method for Ductility of Bitumen and T0605-2011 Asphalt Ductility Test in JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering of People’s Republic of China. The method is applied to the GB/T 4508-2010 and T0605-2011 standards. Determination of petroleum asphalt under the predetermined conditions and in certain temperature, at a certain speed stretch to fracture length, called petroleum asphalt ductility, expressed in cm.

I. Features:

1. It adopts humanized design philosophy. There is no leading screw, lead rail or other components in the test trough. The sample can be easily installed in and the maximum measurement distance can reach 1.5m.

2.  It adopts innovative transmission design. The stretching is stable and synchronous. There is no tremble and the speed is uniform.

3. Three specimens. Suitable to the test standard for asphalt ductility.

4.  The specimen can return and positioning automatically after the determination.

5. Light-touch panel. Water-proof.


II. Specifications:

Power supply AC220V（-5%～+10%），50Hz
Measuring range 1.5m（±10mm）
Heating mode Electrical heating
Heating power 3000W
Bath liquid circulation Magnet pump
Temperature range 5℃~49℃, adjustable,
Digital display, resolution 0.01℃
Temperature accuracy ±0.1℃
Speed 10 mm/min or 50mm/min. Two grades
Measuring accuracy ±1mm
Ambient temperature  -10℃~+35℃
RH  ≤85%
Overall dimension 2365mm×520mm×1000mm
Maximum power consumption 4100W
Product Tags: Asphalt ductility tester , Ductility tester , Asphalt Testing Equipment
