Home > Products > Industrial Elevators > 1000 kg 2 Double Cage Industrial Elevators with Lifting Height 150 m
1000 kg 2 Double Cage Industrial Elevators with Lifting Height 150 m
- T/T L/C D/P D/A
- 7 days
You May Like
-
Double Cabin Construction Cage hoists Material lifting Equipment for civil architecture
-
3200kg High Capacity Single Cage Hoists with Mast Hot-dip Galvanized
-
Rack and Pinion Builder Cage Hoists , 2700kg Construction Elevator for Industrial
-
Mast Hot-dip Galvanized Cage Hoists Lifting Equipment with VFC Control
-
150m Lifting Height Personnel and Material Hosit 1600kg for Contruction Site
-
Construction Lifting Equipment Double Cage Hoists for Materials and Personnel
Product Details
| Brand Name | BORUIDA | Place of Origin | China | |
| Model Number | CH-series |
Product Description
Certification:CE,ISO
1000 / 1000 kg * 2 Industrial elevators with Lifting Height 150 m
Quick Detail:
|
Name |
Other Name |
Brand Name |
Control |
|
Industrial elevators |
Industrial elevators CH 1000/1000 |
BORUIDA |
DOL and FC |
|
Loading Capacity |
1000kg/1000kg |
Certificate |
CE |
Description:
Industrial elevators CH 1000/1000 is installed and dismounted conveniently and can grow as high as the building grows height.The Industrial elevators has such advantages as steady property, safety, reliability,flexible carrying,and good adaptability,etc.,improves working efficiency,and can reduce workers’ working intensity.It is efficient and safety vertical transporting equipment
Applications:
CH serialization of products Industrial elevators is a Rack and Pinion EL. Industrial elevators widely applies to such contruction sites as industrial and civil architecture,bridge,underground,large chimney,and ship industry,etc. It suits the vertical transport of materials and personnels and also suits such different occasions as warehouses,high towers, etc.
Specifications
Standard technical datas of double cars:
|
Parameter |
CH1000/1000 |
CH1600/1600 |
CH2000/2000 |
CH2700/2700 |
CH3200/3200 |
|
Rated |
1000/1000 |
1600/1600 |
2000/2000 |
2700/2700 |
3200/3200 |
|
Rated lifting speed |
0~40 |
0~40 |
0~60 |
0~60 |
0~60 |
|
Rated passenger number |
12/12 |
18/18 |
24/24 |
30/30 |
38/38 |
|
Max. lifting height(m) |
150 |
250 |
450 |
450 |
450 |
|
Engine power(kW) |
2*2*9.5 |
2*2*11 |
2*2*13 |
2*3*18.5 |
2*3*22 |
|
Car inner dimension |
3*1.3*2.5 |
3*1.4*2.5 |
3*1.5*2.5 |
3.2*1.5*2.5 |
3.6*1.6*2.5 |
|
Car weight (kg) |
1400 |
1500 |
1800 |
1950 |
2050 |
|
Mast section weight |
145 |
145 |
163 |
163 |
163 |
|
Mast section dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
|
Safety device type |
SAJ30-1.2 |
SAJ40-1.2 |
SAJ40-1.4 |
SAJ40-1.4 |
SAJ50-2.0 |
|
Hanger rated lifting capacity |
250 |
250 |
250 |
250 |
250 |
|
Rack module |
8 |
8 |
8 |
8 |
8 |
CH series industrial elevators:
1). Car load capacity: 1000kg~3200kg;
2). Lifting speed:33m/min, 0~40m/min;0~60m/min;
3). Increased lifting height on request;
4). Mast section: Painted or hot dipped zinc
5). Car:double car
6
