UEW/PEW/EIW/AIW flat enamaled copper /aluminum /cca wire for transformers
- 10 Ton / Tons per Month
- QINGDAO SHANGHAI TIANJIN
- NF24Q100-01 Carlisle Tensolite Aviation cables
- GSC-13-84943-07 GORE Aviation fiber optic transmission cable
- RCN8687 GORE Advantage products RCN8687 8989 9053
- TE 10612-24-9 Cheminax Spot inventory can be shipped at any time
- Power Accessories Photovoltaic lines Wires UL10269 high voltage cable
- Factory Direct House Wiring 2.5mm2 Single Core Flexible Copper Wire Electrical Wire Installation Electric Cables Price
Product Details
Place of Origin: | Henan, China | Brand Name: | amity or oem | Model Number: | pew 130 |
Type: | Insulated | Application: | Other, motors or transformers | Conductor Material: | Other, copper / aluminum/ CCA |
Conductor Type: | Solid | Insulation Material: | Enameled |
Product Description
ENAMELED WIRE
We mainly supply 130,155,180&200 degree copper/aluminum/CCA gold color enameled wire with high qulaity and competitive price.
Size:
copper enameled wire :0.11-5.0mm /AWG5-AWG37/BWG7-BWG35/SWG6-SWG41
aluminum enameled wire :0.13-6.0mm/ AWG3-AWG36/BWG4-BWG37/SWG4-SWG38
copper clad aluminum enameled wire :0.12-2.5mm
Flat enameled wire:Thickness(a): Φ0.8mm-5.0mm, Width(b): Φ2-16mm
ü Copper enameled wire
standard:
1) 130 degree polyester enameled wire:IEC60317-34
2) 155 degree polyurethane enameled wire:IEC60317-20:2000&MW 79-C
3) 180 degree polyester-imide enameled wire : IEC60317-8:2010& MW 30-C
4) 180 degree polyurethane enameled wire: IEC60317-51:2001& MW 82-C
5) 200 degree polyester-imide overcoated enameled wire IEC60317-13:2010& MW 35-C
ü Aluminum enameled wire
Standard:
1) 130 /155 degree polyester enameled wire: IEC60317-0-3
2) 180 degree modified enameled wire:IEC60317-15
ü CCA copper clad aluminum enameled wire
Solderable Polyurethane enameled CCA wire Class 130
Solderable Polyurethane enameled CCA wire Class 155
Solderable Polyurethane enameled CCA wire Class 180
Polyester enameled CCA wire class 130
Midified Polyester enameled CCA wire class 155
Polyester-imide enameled CCA wire class 180
Test Report of copper electric motor winding wire
Name | Copper Enameled Wire | |||
Type | QZY-2/180/1EIW | |||
Diameter | AWG18 | |||
Standard | IEC60317-8-2010 | |||
Date | Nov 20th,2012 | |||
Test Item | Unit | Technical Requirement | Test Result | |
Appearance |
| bright and clean, Uniform color, | Ok | |
| Conductor Diameter | mm | 1.024±0.011 | 1.022 |
Thickness of insulation film | mm | >= 0.065 | 0.085 | |
Overall Diameter | mm | <=1.121 | 1.107 | |
Mechanical properties | Elongation |
| >=30 % | 38% |
spring-back angle |
| <=41 | 39 | |
Flexibility and adhesion | winding test | 1D,no crack | ok | |
Jerk test | No Crack, and No losing adhesion | ok | ||
scratch resisting(Average) | N | 11.6 | 13.88 | |
scratch resisting(Min) | N | 9.80 | 13.67 | |
Thermal propeties | heat shock | N | 200°C,D=3.55mm,crack free | ok |
cut-through resistance | N | 300°C, 2Min no breakdown | ok | |
Chemical resistance | Resistance to solvent | H | 1H | 1H |
Electrical properties | DC resistance at 20°C | Ω/m | 0.02015-0.02139 | 0.02077 |
Breakdown Voltage /room temperature | KV | >=5.0 kV | 8.0,8.0,8.0,8.0,8.0 | |
Enamel Film continuity |
| <=0 /30m | 0 | |
package |
| Meet the export standards | Ok | |
Quality Control Result |
| Ok |
The physical and mechanical performance of copper clad aluminum wire,copper wire , aluminum wire
conductor Performance | Copper Clad Aluminum Wire | Copper Wire | Aluminum Wire |
Volume ratio of copper (%) | 15 | 109 | 0 |
Specific gravity (g/cm3) | 3.63 | 8.89 | 2.70 |
Length ratio in same wire diameter and unit weight | 2.5: 1 | 1: 1 | 3.29: 1 |
Conductivity (IACS) | 70 | 100 | 62 |
Electric resistivity(Ωmm2) | 0.02462 | 0.01724 | 0.02740 |
Tensile strength (M pa ) | 95-135 | 215-266 | 68-107 |
Elongation (%) | ≥10 | ≥20 | ≥8 |
Winding performance | good | very good | good |
Weight | good | bad | very good |
Soldering performance | very good | very good | bad |
Direct current resistance | good | very good | good |
Learn about us
Henan Amity Industry Co.,Ltd was established in 1996, with an area of 58980 square meters in Zhengzhou city, integrating R&D, production and sales of power cable and wires. We have 600 staff members, including 80 advanced engineers, 98 technicians with different speciality and more than 300 skilled workers. Henan Amity Industry is a specialized enterprise producing all kinds of power cables, wires and cable accessories. Our main products include:AAC, AAAC& ACSR, Aerial bundle cables up to 11kv, PVC insulated wire and flexible wire, Control cable, Enameled wire, PVC insulated power cable, XLPE insulated power cable up to 220kv, Galvanized steel wire, Rubber insulated cable, Mining cable, Fire retardant cable, Flame retardant cable, Connecting wire of electric motor, Underground cable for arming, and Lighting cable.
