PVC 110Kw High Speed Mixers Machines With ZWZ Bearing , SHR Series

Negotiable MOQ: 1 Metric Ton (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

JYM

Place of Origin:

China

Model Number:

SHR

Contact Supplier Request Quote Chat Now

Zhangjiagang Jiu Co. LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name JYM

Place of Origin China

Model Number SHR

Delivery Time:30 working days
Certification:ISO 9001:2000

PVC 110Kw High Speed Mixers Machines With ZWZ Bearing , SHR Series

Descrition:
1. the inside barrel of Heating ＆ Cooling Mixer are made of stainless steel; the outside baiTel of heating Mixer are also in stainless steel, It can resist the corruption of DOP and there is a ￠550mm stainless steel material adding bucket up the pot cover.
2. The Heating Mixer is equipped with 3-pc – type blades.
3. Electric beating device:equipped with temperature tesing device ＆ warm accuse table.
4. The Main roller is sealed in 88888
5. the digital display (made in Changzhou)
6. Siemens contractor
7. the opening ＆ material unloading of the cover adopts liquid pressure control system.
8. decompression starting device : It will decompress the electirc pressure when we start the machine ,It can protect the electric net.
9. Standard electric box 1 pc; step 1 pc , banisters bandrail 1 unit, air compressor machine 1 pc

Applications:

The mixer mainly used homogeneous mixture with PVC, all kinds of resins and other plastic materials.

It mixes and dyes the grain burden of PE, PP and other plastic materials, to dry the hygroscopicity resin forming the type before processing it.

The mixer is absolutely necessary supplement equipment in the front production line of the plastic production factory

Detailed Appendix:

1/ The motor: 110KW 980RPM Dazhong AC motor ;
2/ The inner barrel of mixer are made of stainless steel (thickness of 8mm ) ;
The bottom of the barrel is made of stainless steel (thickness of 8mm) ；
The outermost barrel of heating mixer is packed with 0.8mm stainless steel plate
(DOP corrosion-resistant, easy to clean)；
The mixier is equipped with a stainless steel hopper:150mm*600mm*340mm;
3/ The mixer adopts two-type stainless steel blades:425 RPM ;
The blade at bottom is slotted –type；
4/ The mainshaft is sealed by PTFE and skeleton oil(TTO made in Taiwan) ;
5/ The belt pulley :8 slots with 8 belts；
6/ The frame :welded by high-quality iron plate, surface is painted, strong and beautiful;
7/ The electric heating device, equipped with a temperature thermocouple and temperature control meter;
8/ The bearing:ZWZ bearing；
9/ The mode of pot cover opening and discharge : Pneumatic(to imitate Taiwan)；
The discharge hole:￠180mm；
10/ The electrical box:
(1)Standard electrical box；
(2)Contactor : Delixi Contactor , famous brand in China；
(3)Digital display temperature-control meter ,made in Changzhou；
(4)star-delta starter.
11/ The output :200-250Kg /feeding amount.；

Specifications:

Data Modle	Capacity (L)	Effective Capacity(L)	Motor (KW)	Main shaft speed(rpm)	Heating Method	Discharge Method
SHR-5A	5	3	2.2	600-3000	Self-friction	Hand work
SHR-10A	10	7	3	600-3000
SHR-50A	50	35	7	750/1500	Electricity	Air-operated
SHR-100A	100	75	7/11	650/1300
SHR-200A	200	150	14/22	475/950
SHR-300A	300	225	30/42	475/950
SHR-500A	500	375	47/67	430/860
SHR-800A	800	600	60/90	370/740
SHR-1000A	1000	750	110/160	325/650
