Product Details
Brand Name: | JYM | Place of Origin: | China | Model Number: | SRL-Z800/2500W |
Product Description
Certification:ISO,CE,SGS
Self - Friction High Speed Mixers Horizontal Mixer Unit 1000 - 1250 Kg/Hour
Descrition:
1.Used for the processes of compounding ,mixing,drying as one of the most ideal equipment for the manufactures of profiles and tubes.
2.The cold mixer adopts horizontal structure with the characteristics of large cooling area ,fast speed,more homogenized.
3.The mixer lid is double sealed and opened in the pneumatic way.
4.The electric control system adopts RKC ,Siemens,Mitsubishi,Omron and other famous instruments and control components to realize automatic control components to realize automatic control.
5.Equiped with pulse dust catching device.
6.Both the blades and belt wheel have been specially treated through the balancing machine of static and dunamic.
7.Simple loading system can also be equipped on customer\'s option.
Applications:
SRL-ZW series mixing unit is appliable for mixing,colouring and drying of various resin such as poly,PE,PP,PVC polypropylene,poly chloride etc,and in the process of drying and volatilization of engineering plastics such as ABS PC etc before forming and processing as well as in the mixing of phenolic resin.
The unit combines heat mixing and cool mixing together.The materials after heat mixing can be gotting into cool mixer for cooling automatically,exhausts remaining gass and avoids agglomerates.
It is an ideal equipment for plastics mixing.
Specifications:
Hot Mixing Cold Mixing |
|
Total Volume |
800L 2500L |
Effective Volume |
560L 1800L |
Stir Vane Quantity |
3pc 1pc |
Rotary Speed Of Stir Vane |
0~600r/min 0~80 r/min |
Power |
110Kw 30Kw |
Heat Power |
|
Cooling Method |
By Water |
Consume Time |
6-10 Min/Pot 10-15 Min/Pot |
Air Pressure |
0.39-0.49MPa |
Heating Mode |
Self-friction |
Capacity |
1000~1250 Kg/Hour |
1. Hot mixer Power:110KW,1500RPM, frequency convert motor,ABB Brand;Cooling Mixer Power:30KWHorizontal cycloid Reducer and motor
2. Hot mixer total volume 800L,Effective Volume 560L;Cooling mixer total volume is 2500L and the effective volume is 1800L.
3. The inside barrel of Heating & Cooling Mixer is made of 8mm thickness 304 stainless steel; the outside of heating Mixer are also in stainless steel, It can resist the corruption of DOP and there is a ¢550mm stainless steel material adding bucket up the pot cover.
4. The Heating Mixer is equipped with 3-pc – type blades ,speed:0-660RPM,with dynamic balance treatment.
Cold mixing machine adpots 3 groups of knives, each group with two blades, knives fixed in the knife seat, knives and knife holder are made of stainless steel, blade speed:80RPM.
5. Hot mix machine lid and spout are made of polished aluminum castings,sealed with Silicone seal,Lid is sealed with two chanels, Pneumatic lid and discharge
6. Cold mixing machine uses the top-opening lid,Manually,sealed with silicone seal, Upper and lower inlet spout are stainless Interface,¢ 300mm stainless steel pneumatic valve discharge;
7. Hot mix machine spindle adopts PTFE and skeleton oil seal, Cold mixing machine spindle is sealed with oil seal
8. Electric cabinet 1set,110KW,ABB inverter
9. Capacity:180~250kg/batch
Competitive Advantage:
1. Stable performence
2. Advanced design
3. Convinient control
4.good quality
5.long service life
6.low price
Details:
