Self - Friction Vertical High Speed Mixer For Plastics Mixing

Self - Friction Vertical High Speed Mixer For Plastics Mixing thumbnail-1
Self - Friction Vertical High Speed Mixer For Plastics Mixing photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
JYM
Place of Origin:
China
Model Number:
SRL-Z200/500A
Contact Supplier Request Quote Chat Now
Zhangjiagang Jiu Co. LTD
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name JYM
Place of Origin China
Model Number SRL-Z200/500A
Delivery Time:30 working days
Certification:ISO,CE,SGS

Self - Friction Vertical High Speed Mixer For Plastics Mixing


Descrition:


1. the inside barrel of Heating ＆ Cooling Mixer are made of stainless steel; the outside baiTel of heating Mixer are also in stainless steel, It can resist the corruption of DOP and there is a ￠550mm stainless steel material adding bucket up the pot cover.
2. The Heating  Mixer is equipped with 3-pc – type blades : The cooling Mixer is equipped with  carrying – pole type blades.
3. Electric beating device:equipped with temperature tesing device ＆ warm accuse table.
4. The Main roller is sealed in 88888
5. the digital display (made in Changzhou)
6. Siemens contractor
7. the opening ＆ material unloading of the cover adopts liquid pressure control system.
8. decompression starting device : It will decompress the electirc pressure when we start the machine ,It can protect the electric net.
9. Standard electric box 1 pc; step 1 pc , banisters bandrail 1 unit, air compressor machine 1 pc


Applications:


SRL-ZA series mixing unit is appliable for mixing,colouring and drying of various resin such as poly,PE,PP,PVC polypropylene,poly chloride etc,and in the process of drying and volatilization of engineering plastics such as ABS PC etc before forming and processing as well as in the mixing of phenolic resin.
The unit combines heat mixing and cool mixing together.The materials after heat mixing can be gotting into cool mixer for cooling automatically,exhausts remaining gass and avoids agglomerates.
It is an ideal equipment for plastics mixing.


Specifications:

Hot Mixing               Cold Mixing

Total Volume

200L                           500L

Effective Volume

150L                           320L

Stir Vane Quantity

3pc 1pc

Rotary Speed Of Stir Vane

480/960r/min         0~130 r/min

Power

30/42Kw                     11Kw

Heat Power

Cooling Method

                                  By Water

Consume Time

6-10 Min/Pot             10-15 Min/Pot

Air Pressure

              0.39-0.49MPa

Heating Mode

                Self-friction

Capacity

               400 Kg/Hour

Competitive Advantage:

1. composed of high speed hot mixer,cold mixer...

2. mixing fast and even

3. easily cleaning,

Layout:

Details:
