Automatic 1 Tons Water Purifying Machine With Hydranautics Filter Membrane

Delivery Time:20 working days after down payment.
Certification:CE,SGS

Automatic 1 Tons Water Purifying Machine With Hydranautics Filter Membrane

Quick Detail:

1. Main material: SUS304

2. Capacity range: 1 tons per hour.

3. Main pump brand: Nanfang pump

4. Ultra filter membrane brand: Hydranautics

5. Main electric component brand: Mitsubishi

6. Certificate: CE, SGS

7. Easy operate

1 Tons per hour SUS304 Mineral water treatment plant

Description:

Our mineral water treatment system is planned and designed according to different water quality of different customers; therefore, it’d be better for customers to provide us the water quality test report so that we can design the optimal water treatment equipment for each customer.

The following process is an example for water with normal requested water quality.

Water source → Water supply pump → Multi-media filter→ Activated carbon filter → Sodium ion filter →5μm precision filter → Hollow ultra filter system → Ultraviolet sterilization lamp/Ozone generator sterilizer →Purified water storage tank → Purified water pump → Filling machine

Filters

UF (ultra filter) device

Sterilizing device

Application

food and beverage industry electronic industry medicine industry petroleum industry chemical industry pre-treatment of RO system and pure water treatment water reclamation biotechnology industry surface water treatment

Specifications:

Complete mineral water treatment plant is consist of the following equipments

Description	Qty	Remarks
Raw water tank	1 pc	Normally prepare by user to save the shipping cost/Supply by our company
Booster pump	1 unit	Nanfang Pump
Quartz sand filter	1 unit	Includes up-down distributor, valves
Active carbon filter	1 unit	Includes up-down distributor, valves
Water softener	1 unit	Includes up-down distributor, valves
Security filter	1 unit	5um filter cartridge
PH adjustment system	1 unit
Ultra-filtration system	1 unit
Backwash pump	1 unit	Nanfang pump
Ozone generator	1 unit	Matched
Ozone mixing tower	1 unit	Prepare by users
CIP cleaning system	1 unit	Include water tank, security filter, pump, etc
UF dosing system	1 unit
Pressure gauge1 pc	1batch	includes pure water conductivity monitor
Flow meter	1batch
Pipeline and valves	1batch	Up to actual demand
Electric control system	1 set	PLC control

Competitive Advantage:

1. Stainless steel plate thickness of filters is 4mm, more durable.

2. Be apt to clean the inside with the manhole design.
