Help CenterHCB22-63 Screw Fixed Short Circuit Breaker / Overload Main Circuit Breaker for Power
Related Products
-
General Arc Fault / Ground Fault Mini Circuit Breaker for Overload Protection With 6KANegotiableMOQ: 1 Piece -
20 / 40 Amp Fuse Thermal Mini Circuit Breaker , Red AC / DC Tripped Miniature Circuit BreakersNegotiableMOQ: 1 Piece
-
1P 2P 3P Waterproof Mini Circuit Breaker for Home / Industrial With Icn 6000ANegotiableMOQ: 1 Piece
-
High Breaking Capacity Mini Circuit Breaker , 3 Phase MCB Switch With 6 , 10 , 16 , 20 AmpNegotiableMOQ: 1 Piece
-
AC 240 / 415V High Voltage Miniature Circuit Breakers for Home Overload ProtectionNegotiableMOQ: 1 Piece
Certification:CE
HCB22-63 Screw fixed short circuit breaker / overload main circuit breaker for power
Quick Detail:
Place of Origin: China Brand Name: VECAS Certificate:CE Electricity Type: AC Phase::3 Pole: 4 Rated voltage: AC240/415V Rated current :1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63Specifications and Feature :
1. Protection against both overload and short circuit
2. High breaking capacity
3. Contact position indication
4. Applicable to terminal and pin/fork type busbar connection
Technical Data :
|
Pole No. |
1, 2, 3, 4 |
|
Rated voltage |
AC 240/415V |
|
Rated current (A) |
1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63 |
|
Tripping curve |
B, C, D |
|
Rated breaking capacity (Icn) |
4500A, 6000A |
|
Rated frequency |
50/60Hz |
|
Rated impulse withstand voltage |
6.2kV |
|
Electro-mechanical endurance |
6000 |
|
Connection terminal |
Screw terminal |
|
Connection capacity |
Pillar terminal with clamp |
|
Rigid conductor up to 25mm2 |
|
|
Fastening torque |
2.0 Nm |
|
Installation |
On symmetrical DIN rail 35mm |
|
Panel mounting |
Send Inquiry to This Supplier
