20 / 40 amp Fuse thermal Mini Circuit Breaker , Red AC / DC tripped Miniature circuit breakers
Quick Detail:
Place of Origin: China Brand Name: VECAS Certificate:CE Electricity Type: AC Phase::3 Pole: 4 Rated voltage: AC240/415V Rated current :1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63Specifications and Feature :
■ Protection against both overload and short circuit
■ High breaking capacity
■ Contact position indication
■ Applicable to terminal and pin/fork type busbar connection
Technical Data :
|
Pole No. |
1, 2, 3, 4 |
|
Rated voltage |
AC 240/415V |
|
Rated current (A) |
1, 2, 3, 4, 6, 10, 16, 20, 25, 32, 40, 50, 63 |
|
Tripping curve |
B, C, D |
|
Rated breaking capacity (Icn) |
4500A, 6000A |
|
Rated frequency |
50/60Hz |
|
Rated impulse withstand voltage |
6.2kV |
|
Electro-mechanical endurance |
6000 |
|
Contact position indication |
|
|
Connection terminal |
Screw terminal |
|
Pillar terminal with clamp |
|
|
Connection capacity |
Rigid conductor up to 25mm2 |
|
Fastening torque |
2.0 Nm |
|
Installation |
On symmetrical DIN rail 35mm |
|
Panel mounting |
