Product Details
| Brand Name | KIMCHEN | Place of Origin | China | |
Product Description
magnet tensioner for coil winding machine magnet tension unit for TANAC winding machine wire tensioner magnetic wire tensioner
MTB-02A Magnetic Damping Tension , Mechanical Wire Tensioner
|
Place of Origin: |
Dong Guan China |
|
Brand Name: |
KIMCHEN |
|
Model: |
MTB-A Series |
|
Feature: |
Damper inside |
|
Application: |
Winding machine |
|
Function: |
Tension Control |
|
Product Size: |
130mm*125mm*20mm |
|
Weight: |
0.69KG |
Detailed Product Description:
Magnetic damping tensioner is a magnetic field of media tension constant torque transfer device,
the damping plate doesn’t touch with magnet and without sliding friction, long use life time.
The tension control is extreme stable.
It is simple and easy to fix on machinery, easy to adjust the output torque too,
compact design, small size, always keep stable when it is running in a variety of locations.
Magnetic Damping Tensioner Specifications(eg.enamelled wire)
|
Model |
Use Wire Range (mm) |
Tension Range (gf) |
|
MTB-02A |
φ 0.04— φ 0.08 |
10g— 50 |
|
MTB-03A |
φ 0.09— φ 0.15 |
40g— 150 |
|
MTB-04A |
φ 0.16— φ 0.50 |
160g— 1200 |
|
MTB-05A |
φ 0.40— φ 1.00 |
200g— 2000 |
