Fixed-type CL2 Detect Transmitter
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
Place of Origin
China
QB2000T series fixed-type CL2 detect transmitter (hereinafter referred as probe) is our company’s new product made of imported electrochemical sensor combined with years of experience in designing and producing probe. It can be widely used in metallurgy, petrol, petrifaction, chemistry, light industry, coking, municipal administration, gas, pharmaceutical, sewage dealing and many other special industry and field. It can detect various gas such as flammable gas, O2,H2S,CO,HCN,NO2,SO2,NH3,HCL,CL2,H2 etc. The device adopts intrinsic safety type circuit design, standard 4~20mA two wires signal output, it can transfer in long distance, can get into the DSC system directly, the probe has high sensitivity, quick response, long lifetime, polarization time and many other characteristics; it is among the first class in domestic similar products.
|
Environment Parameter
|
Environment temperature:-20℃~+60℃
|
|
Relative humidity ≤90%R.H.
|
|
|
Technical Parameters
|
Working voltage: 16~30VDC
|
|
Working current: flammable gas is 120mA, others ≤50 mA
|
|
|
Output signal: 4~20mA standard signal two wire type output (flammable gas uses three wire type)
|
|
|
Sensor
|
electrochemical sensor; flammable gas uses catalytic combustion type
|
|
Respond Time
|
T90 less than 30 seconds
|
|
Exterior Structure
|
Weight ≤900g
|
|
Fixing Parameters
|
Fixing type: wall-mounted type
|
|
Transition cable: two core shield cable (flammable gas uses three core shield cable), section 2×1.5mm2, external diameter Ā10mm
|
|
|
Transferring distant ≤1000m
|
|
|
Anti-explosion Class
|
Exd IICT6(used for explosion proofing);ExiaIICT4(used for intrinsic safety type)
|
|
Protection Class
|
IP66
|
