Small Roller Crusher/mini Roller Crusher for Sale

Small Roller Crusher/mini Roller Crusher for Sale photo-1
Small Roller Crusher/mini Roller Crusher for Sale photo-2
Small Roller Crusher/mini Roller Crusher for Sale photo-3
US$ 1000 - 10000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huahong
Place of Origin:
China
Model Number:
2PGC series
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Brand Name Huahong
Place of Origin China
Model Number 2PGC series
Introduction of double roller crusher for slag:

1.Double roll crushers are used for both, primary and secondary crushing. They guarantee a strictly defined final grain size with a minimum of fine grains;
2. Raw materials, secondary materials and by-products such as coke, sinter, coal, soft to medium-hard rock, ore, chalk, slag,broken glass and similar products.


Working principles of double teeth roller crusher for mineral materials:

A roll crusher crushes using compression, with two rolls rotating about a shaft, towards the gap between the rolls. The gap between the rolls is set to the size of product desired, with the realization that the largest feed particle can only be 4 times the gap dimension. The particles are drawn into the gap between the rolls by their rotating motion and a friction angle formed between the rolls and the particle, called the nip angle. The two rolls force the particle between their rotating surface into the ever smaller gap area, and it fractures from the compressive forces presented by the rotating rolls.

Main technical parameters :

Models

Roller diameter

(mm)

Roller length(mm)

Feeding Size  (mm)

Output Size

(mm)

Capacity

(t/h)

Motor
Power(kW)

Weight  (t)

Overall dimension(mm)

 2PGC400x250

 400

 250

 0-350

 15-125

 20-30

 11

 2.8

 2300x1050x900

 2PGC400x500

 400

 500

 0-350

 15-125

 30-50

 22

 3.6

 3000x1400x1200

2PGC450×500

450

500

0-400

15-125

30-60

15

4.5

2260x2200x766

2PGC600×750

600

750

0-500

15-150

60-100

30

7.2

2780x3065x1310

2PGC600×900

600

900

0-500

15-150

80-120

37

7.8

4500x1900x1350

2PGC900×900

900

900

0-700

15-150

150-200

45

13.5

 3945x3405x1895

2PGC1015×760

1015

760

0-700

15-150

150-200

90

18.5

2780x4100x1550





 2PGC920x1200

 920

 1200

 0-800

 20-150

 135-225

 75

 16.5

 3848x3480x1394

 2PGC1200x1500

 1200

 1500

 0-1000

 30-300

 150-250

 110

 26

 3370x3390x1945
