Heavy Hammer Crusher,Single Stage Hammer Crusher,coal Crusher,limestone Crusher
US$ 1 - 200000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huahong
Place of Origin:
China
Model Number:
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Small Jaw Crusher/mini Jaw Crusher Machine for SaleUS$ 500 - 5000MOQ: 1 Set -
Industrial Jaw Crusher/stone Jaw Crusher PriceUS$ 2000 - 20000MOQ: 1 Set
-
Mining Jaw Crusher/stone Crusher Machine for MiningUS$ 2000 - 20000MOQ: 1 Set
-
2013 Granite Jaw Crusher/granite Crusher Machine With Reasonable PriceUS$ 2000 - 20000MOQ: 1 Set
-
Professional Hammer Crusher/heavy Hammer Crusher for SaleUS$ 1000 - 5000MOQ: 1 Set
Brand Name
Huahong
Place of Origin
China
Description:
The hammer crusher also named hammer mill. Hammer Crusher is mainly used for crushing medium-hard or brittle materials with hardness not more than 300Mpa and 15% moisture such as barite, limestone, terrazzo, silica sand stone, coal, coke, gypsum, aluminum sulfate, slag, salt, chalk, blocks, cement, alumen, brick, tile, etc.
Working principle:
The main working part of hammer crusher is rotors with hammer. The rotors consist of main shaft, disk, pin shaft and hammers. The motor drives the rotors to rotate quickly in the crushing cavity. Raw materials enter the crusher through the feed opening and are stricken, impacted, cut and ground by the high-speed hammer to small size. There is a screening plate under the rotor, so that materials with size smaller than the screen mesh will be screened out and others are left to be further hammered and ground until reach the standard size. The size of the final product can be adjusted by changing the screening plate. The gap between the rotors and the screening plate can also be adjusted according to different requirement
Main technical parameters:
The hammer crusher also named hammer mill. Hammer Crusher is mainly used for crushing medium-hard or brittle materials with hardness not more than 300Mpa and 15% moisture such as barite, limestone, terrazzo, silica sand stone, coal, coke, gypsum, aluminum sulfate, slag, salt, chalk, blocks, cement, alumen, brick, tile, etc.
Working principle:
The main working part of hammer crusher is rotors with hammer. The rotors consist of main shaft, disk, pin shaft and hammers. The motor drives the rotors to rotate quickly in the crushing cavity. Raw materials enter the crusher through the feed opening and are stricken, impacted, cut and ground by the high-speed hammer to small size. There is a screening plate under the rotor, so that materials with size smaller than the screen mesh will be screened out and others are left to be further hammered and ground until reach the standard size. The size of the final product can be adjusted by changing the screening plate. The gap between the rotors and the screening plate can also be adjusted according to different requirement
Main technical parameters:
|
Model |
Type |
Rotor diameter
(mm) |
Discharging size
(mm) |
Capacity
(m3/h) |
Motor
|
weight(t)
|
Dimensions
(L×W×H)(mm) |
|
Power(kw)
|
|||||||
|
Single-stage hammer crusher
|
PCΦ400×300
|
≤200
|
≤25
|
5-10
|
11
|
0.8
|
900×670×860
|
|
PCΦ600×400
|
≤250
|
≤30
|
10-22
|
22
|
2.26
|
1200×1050×1200
|
|
|
PCΦ800×600
|
≤250
|
≤35
|
18-40
|
55
|
4.8
|
1310×1180×1310
|
|
|
PCΦ1000×800
|
≤350
|
≤35
|
25-50
|
75
|
5.9
|
1600×1390×1575
|
|
|
PCΦ1000×1000
|
≤350
|
≤35
|
30-55
|
90
|
8
|
1800×1590×1775
|
|
|
PCΦ1250×1250
|
≤350
|
≤35
|
35-65
|
132
|
14
|
2060×1600×1890
|
|
|
PCΦ1400×1400
|
≤350
|
≤35
|
50-100
|
280
|
32
|
2365×1870×2220
|
|
|
PCΦ1600×1600
|
≤350
|
≤35
|
100-150
|
480
|
37.5
|
3050×2850×2800
|
