Home > Products > Cob LED Tube > High Luminous 1498 mm DC 45 - 50 V 24W T8 Cob LED Tube Lights For Indoor
High Luminous 1498 mm DC 45 - 50 V 24W T8 Cob LED Tube Lights For Indoor
- T/T L/C D/P D/A
- 7 days
You May Like
-
1198MM Outside Power DC 45 - 50 V 19W T8 Environment Friendly Cob LED Tube Lighting
-
588mm High Brightness Recyclable AC 100 - 240V 9W T8 Cob LED Tube For Meeting Room
-
High Performance 588MM DC 21 - 25 V 720 - 800 Lm T8 9W Cob LED Tube
-
Energy Saving 1050 - 1125 Lm 14W 894MM DC 33 - 38 V T8 Cob LED Tube
-
1198 mm 16W Inside Power T8 240V 1425 - 1500 Lm Energy-saving Cob LED Tube Light
-
DC24V 830mA 20W High Power Aluminum Alloy Flat 80 - 90 LM / W LED Cob Module
Product Details
| Brand Name | JD | Place of Origin | China | |
| Model Number | JD-T8-1.5M-OC24 |
Product Description
Certification:CCC, CE, RoHS
High Luminous 1498 mm DC 45 - 50 V 24W T8 Cob LED Tube Lights For Indoor
24W COB LED T8 TUBE(Outside Power Supply)
Applications:
The product can be widely used for illumination in supermarket, hotel, showroom, home, meeting-room, factory, museum school hospital and so on.
Specifications:
|
Item No |
Dimensions (D×H) |
LED Type |
Input |
Power |
Power Type |
Power Factor |
Operating Temperature |
|
JDT8-1.5M-OC24 |
D26×L1498 mm |
COB LED |
DC45-50V/ 500mA |
24W |
Outside isolate constant current power supply |
≥0.95 |
-20-60°C |
Optics Parameter
|
luminous flux |
Luminous efficiency |
Lux/1M |
Color Temp |
Color-Rendering Index (Ra) |
Illuminate Angle |
|
1680-1750Lm |
65-75Lm/W |
≥450Lx/1M |
6000±500K |
≥80 |
155° |
|
1920-2000Lm |
|||||
|
1560-1625Lm |
70-80Lm/W |
4000±300k |
|||
|
1800-1875Lm |
Dimension List(Unit:MM)
