24V Energy Efficient 110 * 8mm 2W Flat Strip LED Cob Module For Tube Light

Negotiable MOQ: 1 Kilogram (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Brand Name:

Place of Origin:

China

Model Number:

JD-120032-24V

Contact Supplier Request Quote Chat Now

Guangdong JD Environmental Protection Technology Co., Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

7 days

Product Details
Company Profile
Contact Us

Brand Name JD

Place of Origin China

Model Number JD-120032-24V

Delivery Time:3-5working days after received deposit.
Certification:CCC, CE, RoHS

24V Energy Efficient 110 * 8mm 2W Flat Strip LED Cob Module For Tube Light

Specifications:

Category	Name	Data
Electrical data	Voltage/Current Voltage	DC15-17V/300mA
Voltage	DC24V80mA
Power Consumption	2W
Luminance Efficiency	80-90LM/W
Luminance data	Luminous flux	160-170LM
Color temperature(CCT)	3200K±200K (warm white) 5500K±200K (natural white) 4500K±300K ( cold white) 6000k±300K (day white)
Color rendering index(CRI)	Ra>80
Shell material	Aluminum alloy
Integrated data	Working temperature Ambient temperature	-20°C~60°C
Longevity	≥50000h
Dimensions	L120×W11×H3mm
	Luminous Surface Dimension	110×8mm
	No. Of Chips	25

Flat COB LED Module

1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

2. Low lighting decay, decay less than 3% after 1000 hours.

3. Equable and soft irradiancy, no glaring and eye Protection.

4. Good reliability, no dead bulb and no motting.

5. LED full lighting module can be combined into different LED lights easily.

6. Highly Color-rendering index and lighting effect. Safty, Environment friendly.

Applications:

Flat full lighting module is widely use for LED bulb, LED Tube(such asT5, T8, T10) , LED hard bar, LED down light and so on.

Competitive Advantage:

LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

1. High Lumens:

The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.

2. Equable Lighting:

The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.

3. Better Heat Dissipation:

The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.

Competitive Advantage:

LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.

1. High Lumens:The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.

2. Equable Lighting:The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.

3. Better Heat Dissipation:The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.

Description:

Flat COB LED Module
