30V 1650mA High Brightness 50 Watt LED Cob Module With 50000h Life Span
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
JD
Place of Origin:
China
Model Number:
JD-R040120-30V
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
Environment Friendly 1920 - 2040 LM 24V 24W Round LED Cob ModuleNegotiableMOQ: 1 Piece -
4250 - 4750 LM 2080mA Aluminum Alloy 50W 24V High Power LED Cob ModuleNegotiableMOQ: 1 Kilogram
-
DC 15V 360 - 380 LM Equable Lighting, 33mm 3W Round LED Cob ModuleNegotiableMOQ: 1 Piece
-
20 * 20 * 3 MM Low Voltage DC 24V 410mA 10W LED Cob Module For BulbNegotiableMOQ: 1 Piece
-
24V 11 * 11mm High Power 20W 850 - 950 LM LED Cob Module With High Color-rendering IndexNegotiableMOQ: 1 Piece
Brand Name
JD
Place of Origin
China
Model Number
JD-R040120-30V
Delivery Time:3-5working days after received deposit.
Certification:CCC, CE, RoHS
Certification:CCC, CE, RoHS
30V 1650mA High Brightness 50 Watt LED Cob Module with 50000h Life Span
Flat COB LED Module
1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
2. Low lighting decay, decay less than 3% after 1000 hours.
3. Equable and soft irradiancy, no glaring and eye Protection.
4. Good reliability, no dead bulb and no motting.
5. LED full lighting module can be combined into different LED lights easily.
6. Highly Color-rendering index and lighting effect. Safty, Environment friendly.
Applications:
Round full lighting module is widely used for LED bulb, LED cup , LED spot light, LED down light and so on.
Specifications:
|
Category |
Name |
Data |
|
Electrical data |
Voltage/Current Voltage |
DC15-17V/300mA |
|
Voltage |
DC30V1650mA |
|
|
Power Consumption |
50W |
|
|
Luminance Efficiency |
80-90LM/W |
|
|
Luminance data |
Luminous flux |
4250-4750LM |
|
Color temperature(CCT) |
3200K±200K (warm white) 5500K±200K (natural white) 4500K±300K ( cold white) 6000k±300K (day white) |
|
|
Color rendering index(CRI) |
Ra>80 |
|
|
Shell material |
Aluminum alloy |
|
|
Integrated data |
Working temperature Ambient temperature |
-20°C~60°C |
|
Longevity |
≥50000h |
|
|
Dimensions |
L56XW40XH4mm |
|
|
Luminous Surface Dimension |
25x25mm |
Competitive Advantage:
LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
1. High Lumens:
The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.
2. Equable Lighting:
The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.
3. Better Heat Dissipation:
The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.
Competitive Advantage:
LED cob lamp surface is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.
1. High Lumens:The lumens of our products can reach up to 75-85Lumen per watt for warm white color and 90-100lumen per watt for white color. It is the first-rate in China even in the World.
2. Equable Lighting:The lighting surface is a whole part and avoid the glaring one by one lamp so it can protect humen eyes from glaring.
3. Better Heat Dissipation:The chips are fixed on the aluminum base directly. Due the better dissipation of the aluminum, the heat can be spread out from it quickly so this can lengthen the lifespan of LED.
Description:
Flat COB LED Module
1. LED chip is fixed on aluminum layer of aluminum base PCB. The heat from chip can be spread out through aluminum layer rapidly.2. Low lighting de
