Antistatic Color Coated Steel Coil for Electronic Semi-conductor Industry Pharmaceutical
- T/T L/C D/P D/A
- 7 days
You May Like
-
PVDF Fluorocarbon Color Coated Steel Coil DX51D+Z, DX51D+AZ, S350GD+Z
-
EN 10147 DX51D+AZ, JIS G 3322 CGLCC, ASTM A755/A792 CS Color Coated Hot Dip Al-Zn Steel
-
EN 10147 DX51D+Z JIS G 3312 CGCC (SPCC), ASTM A755/A653M CS Color Coated Galvanized Steel
-
Cold-rolled Deep Drawing Galvalume Color Coated Steel Coil DX52, DX53, SPCD, SPCE
-
Q195 Q250 Q350 Structure Color Coated Steel Coil Base Steel S280GD+Z, S350GD+Z, S550GD+AZ
-
EN JIS ASTM Hot Dipped Galvanized Color Coated Steel Coil 0.18mm-1.6mm, Layer 2/2 2/1
Product Details
| Brand Name | KUNHU, MA STEEL, BAO STEEL | Place of Origin | China | |
Product Description
Antistatic color coated steel coil for electronic semi-conductor industry pharmaceutical
The working principle of the antistatic prepainted steel sheet is to add some conducting materials in the insulating polyester coating, which gets the former insulated coating, become a semiconductor. Being assorted with the earthing system of the construction, the accumulated static electricity on the surface of the prepainted steel sheet that is sourced from air convection or fabric friction is conducted into the earthing system and then disappears.
Applications:
Mainly used in antistatic, high cleanness and bacteria-free environments, covering: electronic semi-conductor industry, foodstuff processing industry, pharmaceutical industry, hospitals, etc.
Specifications:
|
Base Metal |
Hot dipped galvanized steel, Hot dipped galvalume steel |
|
Thickness |
0.18mm-1.6mm |
|
Width |
600mm-1500mm |
|
Coil ID |
508mm, 610mm |
|
Layers of the coating |
2/2(2 layers of top coating/2 layers of bottom coating); 2/1(2 layers of the top coating, 1 layer of bottom coating); |
|
Color |
According to customers’ request |
|
Thickness of the coating |
25um-75um |
|
Surface |
Film coverd |
