Products Feature-Stability, Of course SBC!
1.High refresh rate reach 2000HZ for one second, so it can remedy the twitter and flicker of the image caused by lack frame especially obvious.
2.P20 is difference from the normal screen, with more flexible installation solution, it can be installed more easy.
3.The super thin screen KU69W always stay at the most advanced front for the low power consumption. Low detrimental material or life span.
4.Use SBC patent connection system to ensure no gap between the cabinet joint of the large screen without loosen power supply and flicking ,twittering signals and screen black.
5. Best equality, commendably solve the problem of the mosaic, have the excellent consistency of light.
Products Parameter-Stability,Of course SBC!
| Type | Outdoor Led Display |
| Best Viewing Distance(m) | 69 |
| Pixel Pitch(mm) | 20 |
| Pixel Density(Dots/sqm) | 2500 |
| Configuration | 1R1G1B |
| Module Size(mm) | 320*160 |
| Unit Box Pixel(Dots) | 64*48 |
| Cabinet Size(WxHxT) | 1280* 960*120 |
| Cabinet Weight(Kg) | 60 |
| Brightness(cd/sqm) | 8000 |
| Refresh Frame Frequency | 1000Hz |
| MTBF(H) | 10000 |
| Maximum Power Consumption(W/sqm) | 550 |
| Average Power Consumption(W/sqm) | 300 |
| Left/right Viewing Angle(Degree) | 140° |
| Grey Scale | 12bit |
| Display Color | 16777216colors |
| Brightness Adjust | 256grade automatic,100grade manual |
| IP Standard | IP65 |
| Display Module Brightness Uniformity | 5% |
| Pixels Out Of Control Rate(Dots) | 1/100000Dots |
| Life Span(H) | 100000H |
| Operating Voltage | AC220V/50Hz&AC110V/60Hz available |
| System Working Environment Temperature | —20°C~+60°C |
| System Working Environment Humidity | 10%RH~90%RH |
