1.The second popular outdoor second most used LED screen, the area is from 20 to 500 sqm, which can be viewed from 20 – 500m away the screen.
2.Super thin KU69W is different from the normal screen, with more flexible installation solution, it can be installed more easily.
3.Super light and super thin which can be coordinated to the installation environment, meanwhile it supports the display mode vertical and horizontal and hanging.
4.It is greatly convenient for clients to install it according to the real condition.
5.It can realized the easy configuration to the local area net(LAN) and manage the server software.
6.No matter at the low power consumption, low detrimental material or life span, super thin screen KU69W stays at the most advanced front.
|
Type |
Outdoor Full Color Display |
|
Best Viewing Distance(m) |
69 |
|
Pixel Pitch(mm) |
20 |
|
Pixel Density(Dots/sqm) |
2500 |
|
Configuration |
1R1G1B |
|
Module Size(mm) |
256*128 |
|
Unit Box Pixel(Dots) |
64*48 |
|
Cabinet Size(WxHxT) |
1280*960*160 |
|
Cabinet Weight(Kg) |
65 |
|
Brightness(cd/sqm) |
7000 |
|
Refresh Frame Frequency(Hz) |
1000 |
|
MTBF(H) |
10000 |
|
Maximum Power Consumption(W/sqm) |
550 |
|
Average Power Consumption(W/sqm) |
300 |
|
Left/right Viewing Angle(Degree) |
140° |
|
Grey Scale |
12bit |
|
Display Color |
16777216colors |
|
Brightness Adjust |
256 grade automatic,100 grade manual |
|
IP Standard |
IP65 |
|
Display Module Brightness Uniformity |
5% |
|
Pixels Out Of Control Rate(Dots) |
1/100000 Dots |
|
Life Span(H) |
100000 |
|
Operating Voltage |
AC220V/50Hz&AC110V/60Hz available |
|
System Working Environment Temperature |
–20°C~+60°C |
|
System Working Environment Humidity |
10%RH~90%RH |
