P20 Outdoor Full Color Led Display Screen for Advertising

1.Humanized design, convenient for installation and maintenance, flexible usage in any time anywhere, with cost advantage, suitable for large area landscaping, windproof, waterproof, apply to all kinds of installation ways, can show life-like scenery, and create extremely illusion for abstract composition.
2.All-aluminum structure module, only one third of normal led display weight, and also has excellent weather resistance.
3.Fast installation, good transparent and ventilation rate, larger pixel pitch, cost-effective.
4.Bright color, fast response, good showing effect, high reliability, long life span, environmental protection and energy-saving
5.Easy maintenance, good heat dissipation, high stability.
6.Mainly used for indoor-outdoor concert and for stage background, building wall, advertising screen, nightclub and dancing hall.

Type	Outdoor  Full Color Display
Best Viewing Distance(m)	69m
Pixel Pitch(mm)	20mm
Pixel Density(Dots/sqm)	2500Dots/sqm
Configuration	1R1G1B
Module Size(mm)	320mm x160mm
Unit Box Pixel(Dots)	64Dots x48Dots
Cabinet Size(WxHxT)	1280mm x 960mm x120mm
Cabinet Weight(Kg)	60Kg
Brightness(cd/sqm)	8000cd/sqm
Refresh Frame Frequency	1000Hz
MTBF(H)	10000H
Maximum Power Consumption(W/sqm)	550W/sqm
Average Power Consumption(W/sqm)	300W/sqm
Left/right Viewing Angle(Degree)	140°
Grey Scale	12bit
Display Color	16777216colors
Brightness Adjust	256grade automatic,100grade manual
IP Standard	IP65
Display Module Brightness Uniformity	5%
Pixels Out Of Control Rate(Dots)	1/100000Dots
Life Span(H)	100000H
Operating Voltage	AC220V/50Hz&AC110V/60Hz available
System Working Environment Temperature	—20℃~+60℃
System Working Environment Humidity	10%RH~90%RH
