Help CenterTPH Dual Output DC/DC Converters
US$ 1
≥88888999999 Pieces
Key Specifications
Get Latest Price
Brand Name:
Top Power
Place of Origin:
China
Model Number:
TPH Series
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
7 days
Related Products
-
TPJ 6kVDC Isolated DC/DC ConvertersUS$ 0.55MOQ: 2147483647 Pieces -
TPK DC/DC Converters Power Converters Integrated CircuitsUS$ 0.55MOQ: 2147483647 Pieces
-
TPL Single Output DC/DC Converters Power SupplyUS$ 1MOQ: 2147483647 Pieces
-
TPLE DC/DC Converters Power Supply Integrated CircuitUS$ 0.55MOQ: 2147483647 Pieces
-
TPNA 1500VDC Isolated DC/DC ConvertersUS$ 1MOQ: 2147483647 Pieces
Brand Name
Top Power
Place of Origin
China
Model Number
TPH Series
Weight
5g
Application
all
Frequency
hz
Rated Voltage
vdc
Rated Torque
/
Rated Input Power
/
| Summary Description: | |||||||||||||
|
2W Isolated Dual Output DC/DC Converters power supply module The TPH series of industrial temperature range DC/DC converters are the standard buliding blocks for on-board point-of-use power systems. They are ideally suited for providing dual rail supplies on single rail boards | |||||||||||||
| Basic Terms: | |||||||||||||
| 1 | Type | TPH Series | |||||||||||
| 2 | Efficiency | up to 86% | |||||||||||
| 3 | Power density | up to 1.44W/cm3 | |||||||||||
| 4 | Wide temperature performance | at full 2 Watt load, –40°C to 85°C | |||||||||||
| 5 | Related certificate | RoHS compliant | |||||||||||
| 6 | Isolation voltage | 1kVDC | |||||||||||
| 7 | Iutput voltage | 5V, 12V, 24V & 48V input | |||||||||||
| 8 | Output voltage | 5V,9V.12V and 15V Output | |||||||||||
| 9 | Pin connection/14 PIN DIP | 1(-Vin),7(NC),8(OV),9(+VOUT),11(-Vout),14(+Vin) | |||||||||||
| Pin connection/7 PIN SIIP | 1(+Vin),2(-VIN),4(-VOUT),5(OV),6(+Vout) | ||||||||||||
| 10 | MOQ | 1 pc (no ltimited for considered the long coorperation relations) | |||||||||||
| 11 | Terms of payment | Western Union,T/T | |||||||||||
| 12 | Terms of delivery | DHL / UPS / EMS / TNT | |||||||||||
| 13 | Delivery time | 7-12 working days | |||||||||||
Part Number |
Nominal Input Voltage |
Output Voltage |
V |
V |
|
TPH0505D |
5 |
±5 |
TPH0509D |
5 |
±9 |
TPH0512D |
5 |
±12 |
TPH0515D |
5 |
±15 |
TPH0505S |
5 |
±5 |
TPH0507S |
5 |
±7.2 |
TPH0509S |
5 |
±9 |
TPH0512S |
5 |
±12 |
TPH0515S |
5 |
±15 |
TPH0524S |
5 |
±24 |
TPH1205D |
12 |
±5 |
TPH1209D |
12 |
±9 |
TPH1212D |
12 |
±12 |
TPH1215D |
12 |
±15 |
TPH1224D |
12 |
±24 |
TPH1205S |
12 |
±5 |
TPH1209S |
12 |
±9 |
TPH1212S |
12 |
±12 |
TPH1215S |
12 |
±15 |
TPH1224S |
12 |
±24 |
TPH1505D |
15 |
±5 |
TPH1505S |
15 |
±5 |
TPH1515S |
15 |
±15 |
TPH2405D |
24 |
±5 |
TPH2409D |
24 |
±9 |
TPH2412D |
24 |
±12 |
TPH2415D |
24 |
±15 |
TPH2424D |
24 |
±24 |
TPH2405S |
24 |
±5 |
TPH2409S |
24 |
±9 |
TPH2412S |
24 |
±12 |
TPH2415S |
24 |
±15 |
TPH2424S |
24 |
±24 |
TPH4805D |
48 |
±5 |
TPH4809D |
48 |
±9 |
TPH4812D |
48 |
±12 |
TPH4815D |
48 |
±15 |
TPH4805S |
48 |
±5 |
TPH4809S |
48 |
±9 |
TPH4812S |
48 |
±12 |
|
TPH4815S
|
48 |
±15 |
