TPK DC/DC Converters Power Converters Integrated Circuits

TPK DC/DC Converters Power Converters Integrated Circuits thumbnail-1
TPK DC/DC Converters Power Converters Integrated Circuits thumbnail-2
TPK DC/DC Converters Power Converters Integrated Circuits thumbnail-3
TPK DC/DC Converters Power Converters Integrated Circuits photo-1
TPK DC/DC Converters Power Converters Integrated Circuits photo-2
TPK DC/DC Converters Power Converters Integrated Circuits photo-3
US$ 0.16 ≥6.6666666667778E+20 Pieces
Key Specifications
Get Latest Price
Brand Name:
Top Power
Place of Origin:
China
Model Number:
TPK DC/DC Converters
Contact Supplier Request Quote Chat Now
Guangzhou Top Power Electronics Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Top Power
Place of Origin China
Model Number TPK DC/DC Converters

RoHS compliant

Efficiency from 80%

Input voltage: 3.3V, 5V,12V, 15V,24V，48V

Operating temperature: -40℃to 105℃

UL 94V-0 package   material

Output voltage: 3.3V,5V, 7.2V,9V, 12V, 15V,18V, ,24V / ±5V, ±9V, ±12V, ±15V,±24V

Industry standard   pinout

3KVDC isolation (1   minute)

CE certification

SELECTION GUIDE

Part Number

Nominal Input Voltage

Output Voltage

Output Current(Max./Min)

Load Regulation (Max)

Efficiency (Typ.)

Package Style

V

V

mA

%

%

82

82

86

86

87

84

87

87

89

84

TPK0303SA

3.3

3.3

606/60.6

7.2

82

SIP

TPK0305SA

3.3

5

400/40

7.2

82



SIP

TPK0503SA

5

3.3

606/60.6

7.2

82

SIP

TPK0505SA

5

5

400/40



7.2



82



SIP

TPK0507SA

5

7.2

278/27.8



5.8



80



SIP

TPK0509SA

5

9

222/22.2



5.8



86



SIP

TPK0512SA

5

12

167/16.7



5.0



86



SIP

TPK0515SA

5

15

133/13.3



4.6



87



SIP

TPK1205SA

12

5

400/40

/

4.9

82



SIP

TPK1209SA

12

9

222/22.2



3.0

87



SIP

TPK1212SA

12

12

167/16.7



2.9

87



SIP

TPK1215SA

12

15

133/13.3



2.5

89



SIP

TPK1224SA

12

24

83.3/8.33

5.0

83

SIP

TPK1515SA

15

15

133/13.3

2.5

84

SIP

TPK2405SA

24

5

400/40

4.9

82

SIP

TPK2412SA

24

12

167/16.7

5.0

84

SIP

TPK2415SA

24

15

133/13.3

2.5

84

SIP

TPK2424SA

24

24

83.3/8.33

5.0

83

SIP

TPK0505S

5

±5

±200/±20



6.3

82



SIP

TPK0509S

5

±9

±111/±11.1



5.4

86



SIP

TPK0512S

5

±12

±83/±8.3



4.8

86



SIP

TPK0515S

5

±15

±67/±6.7



5.3

87



SIP

TPK0524S

5

±24

±41.65/±4.165

5.0

83

SIP

TPK1205S

12

±5

±200/±20



3.9

82



SIP

TPK1209S

12

±9

±111/±11.1



2.9

86



SIP

TPK1212S

12

±12

±83/±8.3



2.8

87



SIP

TPK1215S

12

±15

±67/±6.7



2.5

87



SIP

TPK1515S

15

±15

±67/±6.7

2.5

87

SIP

TPK2405S

24

±5

±200/±20



3.9

82



SIP

TPK2409S

24

±9

±111/±11.1



2.9

86



DIP

TPK2412S

24

±12

±83/±8.3



2.8

87



SIP

TPK2415S

24

±15

±67/±6.7

2.5

87

SIP

TPK2424S

24

±24

±41.65/±4.165

5.0

83

SIP

TPK0305DA

3.3

5

400/40

7.2

82



DIP

TPK0505DA

5

5

400/40



7.2



82



DIP

TPK0509DA

5

9

222/22.2



5.8



86



DIP

TPK0512DA

5

12

167/16.7



5.0



86



DIP

TPK0515DA

5

15

133/13.3



4.6



87



DIP

TPK1205DA

12

5

400/40



4.9

82



DIP

TPK1209DA

12

9

222/22.2



3.0

87



DIP

TPK1212DA

12

12

167/16.7



2.9

87



DIP

TPK1215DA

12

15

133/13.3



2.5

89



DIP

TPK1515DA

15

15

133/13.3

2.5

84

DIP

TPK2405DA

24

5

400/40

4.9

82



DIP

TPK2412DA

24

12

167/16.7

5.0

84

DIP

TPK2424DA

24

24

83.3/8.33

5.0

83

DIP

TPK0505D

5

±5

±200/±20



6.3

82



DIP

TPK0509D

5

±9

±111±/11.1



5.4

86



DIP

TPK0512D

5

±12

±83/±8.3



4.8

86



DIP

TPK0515D

5

±15

±67/±6.7



5.3

87



DIP

TPK1205D

12

±5

±200/±20



3.9

82



DIP

TPK1209D

12

±9

±111/±11.1



2.9

86



DIP

TPK1212D

12

±12

±83/±8.3



2.8

87



DIP

TPK1215D

12

±15

±67/±6.7



2.5

87



DIP

TPK1515D

15

±15

±67/±6.7

2.5

87

DIP

TPK2405D

24

±5

±200/±20



3.9

82



DIP

TPK2412D

24

±12

±83/±8.3



2.8

87



DIP

TPK2424D

24

±24

±41.65/±4.164

5.0

83

DIP

TPK4805SA

48

5

400/40

4.9

78

SIP

TPK4818SA

48

18

111/11.1

2.9

78

SIP

Add Suffix “P” for Continuous Short Circuit Protection, for example TPK0505SAP.

Summary Description: Integrated Circuits
 3kVDC Isolated 2WSingle and dual Output DC/DC Converters

The TPK series of industrial temperature range DC/DC converters, available industry standard SIP packaging,The TPK offers 3KVDC isolation with 5V output minimum efficiency of 80% at 2W. The un-regulated TPK series has output voltage set point accuracy of 6% in conjunction with excellent load regulation for this converter.

The TPK series are miniature, isolated 2W DC/DC converters in a SIP package. They offer the ideal solution in many space critical applications for board level power distribution. The internal SMD construction makes it possible to offer a product with high performance at low cost. The series offers smaller size, improved efficiency, lower output ripple noise and 3KVDC isolation.





Basic Terms:
1 Type TPK Series
2 Efficiency from 80%
3 Power density  1.33W/cm3
4 Pinout Industry standard pinout
5 Related certificate RoHS compliant
6 Isolation voltage 3kVDC  (1 minute)
7 Input voltage  5V , 12V
8 Output voltage 5V, 9V, 12V,  15V
9 Wide temperature at full2 Watt load, –40°C to 85°C
10 Package material UL 94V-0 package material
11 Temprature characteristic Wide temperature performance at full 1 Watt load, –40°C to 85°C
12 MOQ 1 pc (no ltimited for considered the long coorperation relations)
13 Terms of payment Western Union,T/T
14 Terms of delivery DHL / UPS / EMS / TNT
15 Delivery time 7-12 working days
Product Tags: DC/DC Converters , DC/DC Converter , power converters
