8 Port 802.3af Standard Poe Switch Poe Adapter

Name: 8 Port 802.3af Standard Poe Switch Poe Adapter
Brand: SinoV
Availability: InStock

FOB Price

US$ 100 - 100 / Piece

5 Pieces(Min. Order)

Payment TermsT/T L/C D/P D/A
Delivery Detail7 days

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	SinoV		Place of Origin	China
Model Number	sinov-switch-8-m-af

Product Description

SinoV-switch-8-M-AF is a 8 port network powered 10/100M self-adapting Ethernet switch. It has a common UPLINK port to connect to the up level network device, such as common switch and router. It has 8 POE output ports which all match IEEE802.3af standard. Each POE port can offer max.15.4W power. All ports support Auto MDI/ MDIX function.

SinoV-switch-8-M-AF offers a simple, economical,high performance solution, compatible with 100M networks. It is very easy to install, and to operate and provides flexibility to improve workgroup performances. All the advantages show that this switch is the best choice to improve the sever efficiency. The 8 PSE ports simultaneously offer data transmit channels and supply power for routers, switches, wireless APs, IP phones, industrial network terminals, IP cameras and other equipments. It provides the power supply to these appliances without the necessity of separate power cables, improves the reliability and simplifies the installation of the Ethernet power system.

NOTE: use TI 2384 chip inside. full support IEEE802.3af internation standard

1 Comply with IEEE802.3 10BASE-T for Ethernet and IEEE802.3u 100BASE-TX for fast Ethernet standards.
2 Compliance IEEE802.3af for POE
3 it have 8 ports of half duplex /full duplex self-adapting RJ-45,with 100Mbps for each ports.8 POE ports,which can automatically identify the power ( max power as 15.4W of each)
4 Each port supports MDI/MDIX, which can automatically adjust the buffer to balance the Ethernet loading and to avoid data package missing.
5 Each port has auto detecting and correcting polarity ability
6 Support MAC address auto-learning and auto-aging
7 Panel lamp monitors the working status and helps to resolve faults easily
7 Highly insure the data integrality and speed matching
9 Highest speed for data transmitting and data filtering
10 Strong compatibility in Ethernet application to keep user lowest cost

General
Standards	IEEE802.3 10BASE-T for Ethernet IEEE802.3u 100BASE-TX for fast Ethernet IEEE802.3af POE
Protocol	CSMA/CD Ethernet
Data Transmit Rate	Ethernet:10Mbps(half-duplex)20Mbps(duplex) Fast Ethernet:100Mbps(half-duplex)200Mbps(duplex)
Topology Structure	Star topology
Physical Medium	10BASE-T: CAT3,4,5 UTP(max. length 100m ) EIA/TIA-568 100ohm STP(max. length 100m) 100BASE-TX: CAT 5 or up UTP(max. length 100m) EIA/TIA-568 100ohm STP(max length 100m)
The number of Port	8
TX / RX	8 th
LED Display	Power ,UPLINK, Error, ACTIVE
Transfer Mode	Storage transmit
MAC Address	Auto Study,Auto Update
Package Filter Rate	10BASE-T:14880pps/port 100BASE-TX:148800pps/port
Package Transmit Rate	10BASE-T:14880pps/port 100BASE-TX:148800pps/port
Physical Environment
Input	AC Adapter(AC100-240V ~50-60HZ,DC48V/6A)
Power	No Load :10W(MAX) Full Load:140W
Operating Temperature	-20~70°c
Storage Temperature	-40 ~ 70°c
Humidity	5%~95% unfrozen
Dimensions	18011832mm
