24 Port 100M 802.3af POE Midspan Poe Adapter
US$ 340 - 340
/ Piece
5 Pieces(Min. Order)
- T/T L/C D/P D/A
- 7 days
You May Like
-
4 Port 802.3af Standard Poe Switch With 1 Uplink Port
-
8 Port 802.3af Standard Poe Switch Poe Adapter
-
8 Port 802.3at Standard Gigabit Poe Switch Poe Adapter
-
16 Port 802.3af Standard Poe Switch Poe Adapter
-
SinoV-AP-W500 150M Inwall Wireless AP Inwall AP
-
SinoV-TE420E 4 E1 Pci-e Asterisk Card All Driver as Digium
Product Details
| Brand Name | SinoV | Place of Origin | China | |
| Model Number | sinov-midspan-24-M-AF |
Product Description
SINOV-MIDSPAN-24-M-AF is a 24-port network powered midspan. It has 48 RJ45-port. Its 24 ports in up line can be used as UPLINK to connect the upper switch or other equipments, its 24 ports in down line can be used as the data and power transmitting (POE port), ,each port matches IEEE802.3af standard, each port can offer the max power as 15.4W. The net cables between up line and down line are corresponding .All ports support Auto MDI/ MDIX function.
SINOV-MIDSPAN-24-M-AF offers a simple, economical,high performance solution, compatible with 10/100M networks. It is very easy to install, and to operate and provides flexibility to improve workgroup performances. All the advantages show that this midspan is the best choice to improve the sever efficiency. The 24 ports simultaneously offer data transmit channels and supply power for routers, switches, wireless APs, IP phones, industrial network terminals, IP cameras and other equipments. It provides the power supply to these appliances without the necessity of separate power cables, improves the reliability and simplifies the installation of the Ethernet power system.
NOTE: use TI 2384 chip inside. full support IEEE802.3af internation standard
1 Comply with IEEE802.3 10BASE-T for Ethernet and IEEE802.3u 100BASE-TX for fast Ethernet standards.
2 Compliance IEEE802.3af for POE
3 48 ports of half duplex /full duplex self -adapting RJ-45, with 100Mbps for each ports.
4 24 POE ports , which can automatically identify the power ( max power as 15.4W of each)
5 Each port supports MDI/MDIX, which can automatically adjust the buffer to balance the Ethernet loading and to avoid data package missing.
6 Each port has auto detecting and correcting polarity ability
7 Support MAC address auto-learning and auto-aging
8 Panel lamp monitors the working status and helps to resolve faults easily
9 Highly insure the data integrality and speed matching
10 Highest speed for data transmitting and data filtering
11 Strong compatibility in Ethernet application to keep user lowest cost
|
General
|
|
|
Standards
|
IEEE802.3 10BASE-T for Ethernet
IEEE802.3u 100BASE-TX for fast Ethernet
IEEE802.3af POE
|
|
Protocol
|
CSMA/CD Ethernet
|
|
Data Transmit Rate
|
Ethernet:10Mbps(half-duplex)20Mbps(duplex)
Fast Ethernet:100Mbps(half-duplex)200Mbps(duplex)
|
|
Topology Structure
|
Star topology
|
|
Physical Medium
|
10BASE-T:
CAT3,4,5 UTP(max. length 100m )
EIA/TIA-568 100ohm STP(max. length 100m)
100BASE-TX:
CAT 5 or up UTP(max. length 100m)
EIA/TIA-568 100ohm STP(max length 100m)
|
|
The number of Port
|
48 ports (24 ports in up line are standard net ports,24 ports in down line are POE ports as data and power transfer)
|
|
TX / RX
|
Any of 48 ports
|
|
LED Display
|
Power ,UPLINK, Error, ACTIVE ,PSE power
|
|
Transfer Mode
|
Storage transmit
|
|
MAC Address
|
Auto Study,Auto Update
|
|
Package Filter Rate
|
10BASE-T:14880pps/port;
100BASE-TX:148800pps/port
|
|
Package Transmit Rate
|
10BASE-T:14880pps/port;
100BASE-TX:148800pps/port
|
|
Physical Environment
|
|
|
Input
|
AC Adapter(AC100-240V ~50-60HZ,DC48V/9A)
|
|
Power
|
No Load :15W(MAX)
Full Load:380W
|
|
Operating Temperature
|
-20~70°c
|
|
Storage Temperature
|
-40 ~ 70°c
|
|
Humidity
|
5%~95% unfrozen
|
|
Dimensions
|
1U
|
|
Net Weight
|
5 kg
|
