Detailed Product Description
| Color: | Black | Length: | 5M |
| Time Frequency: | 85Mhz | Connector: | SDR 26pin |
| Locking: | Thumbscrew | Molding: | Yes |
| Attribution: | With Ferrites | Application: | Machine Vision,Industrial Equipment,Vision Cameras |
Mini Cameralink Cable Molding Type with Screw Locking and EMI Ferrite Good Performance
This CameraLink cable with molding ferrite to reduce the enviroment electromagnetic interference.
Description:
Color |
Black |
Outer Diameter |
9.5 ± 0.1 mm |
Temperature Rating |
80°C (per UL20276) |
Conductor Resistance at 20C |
less than 240 W/km |
Insulation Resistance |
over 100 MW-km |
Withstanding:Voltage |
350 VAC for 1 minute |
Voltage Rating |
30 VAC |
Characteristic Impedance |
100 ± 10 W |
Propagation Speed |
4.7 ns/m ± 10% |
Skew (within pair) |
50 ps/m maximum |
RoHS Compliant UL Approval |
Yes |
1,AIA standard
2,SDR 26pin Solder and Molding type
3,0.3meters to 10meters length can be offered
4,180 degree straigth end and 90degree up/down right angled molding type is available
5,5.0meters 85Mhz
6,Full shielded and signal low attenuation
7,100% factory tested
8,1~2years guarantee
