Laser Metal Cutting Machine MC 1325
- Qingdao Port China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
MC 1390 Reci 150w / 180w Laser Mix Cutting Machine
-
MC1390 260w / 280W Laser Mix Cutting Mild Steel Machine
-
MC1390 280W Laser Mix Cutting 2mm Carbon Steel Machine
-
MC1390 EFR 280W Laser Mix Cutting 2mm Stainless Steel ss Machine
-
MC1390 EFR 280W Laser Mix Cutting Machine FromJack Lee
-
MC 1390 Reci 180w Mix Laser Cutting 1.5 mm Steel Machine
Product Details
| Condition | New | Laser Type | CO2 | |
| Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Metal, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Cutting Thickness | 12mm | |
| Cutting Area | 1300*2500mm | Cutting Speed | 36000mm/min | |
| CNC or Not | Yes | Cooling Mode | Water Cooling | |
| Control Software | lasercut6585 | Graphic Format Supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | |
| Place of Origin | Shandong, China | Brand Name | MC | |
| Model Number | 1325 | Certification | CCC, CE, GS, ISO, SGS, UL, Other, CCC, CE, GS, ISO, SGS, UL, FDA | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Laser metal cutting machine MC 1325
cnc laser cutting machine
1) metal cutting machine 150watt co2 laser features:
Two heads can be engraved or cut off at the same time. Or one of two heads work alone. please attention that dual head to do same things is operated by control system. to some extend, high efficiencey in a short producing time.
2) metal cutting machine 150watt co2 laser parameters :
Model | MC1325 | Option |
Working Area | 1300*2500mm | According to Demands |
Laser Power | 60w/80w/100w/130w//150w | |
Laser Type | CO2 Sealed Laser Tube , 10.6μm | |
Cooling Type | Water Cooling | |
Engraving Speed | 0-60000mm/min | |
Cutting Speed | 0-40000mm/min | |
Laser Output Control | 0-100% set by software | |
Min. Engraving Size | Chinese: 2.0mm*2.0mm, English Letter: 1.0mm*1.0mm | |
Highest Scanning Precision | 4000DPI | |
Locating Accuracy | ≤+0.01mm | |
Controlling Software | DSP Control System | |
Graphic Format Supported | DST PLT BMP DXF DWG AI LAS,etc | |
Compatible Software | CORELDRAW,PHOTOSHOP, AUTOCAD,TAJIMA,etc. | |
Color Separation | Yes | |
Drive System | High-precision 3-phase Stepper Motor | |
Auxiliary Equipments | Exhaust Fan and Air Exhaust Pipe | |
Power Supply | AC110V/220V+10%,50HZ/60HZ | |
Working Environment | Temperature:0-45C,Humidity 5-95%(No Condensate Water) | |
3) metal cutting machine 150watt co2 laser advantages:
- MC 1325 is a mixing cutting machine, widely used in metal and nonmetal cutting and engraving.
- Japan Yaskawa Servo motor to ensure the high precision, running stable and long-operation.
- Special follow up laser cutting head, which can sense a distance from the nozzle to the metal surface and follow the surface up and down to automatically adjust the certain focus distance for keeping high precision.
- RDCAD/CAM Laser Work control system with English Color screen display and compatible with USB, PC and various memeries.
- HIWIN square rail with high precision and stable of cutting.
- The weight of the cutting machine is about 1.2tons, much heavier than others, to reduce the precision error caused by machine vibration.
- Low running cost which is about 5KVA/hour.
4) metal cutting machine 150watt co2 laser applicable materials:
Acrylic , perspex, glass, wood, stone, marble, gravestone, rubber, leather,fabric, paper, cltoh, dual-colour boards.
5) metal cutting machine 150watt co2 laser applicable industries:
1.artcrafts: wood,bamboo, elephant's tusk,bone, leather, marble,sea shell etc.
2. advertisement: double color board,acrylic engraving and cutting,label engraving,crystal etc.
3. model industry: sand table constructtion model,plane model etc.
4. packing:rubber engraving,plastic,doubling plate,die board cutting etc.
5. leather and cloth process:compound leather,man-made leather,fabric,fur ,toy etc.
6. other industry : marble,granite,glass,crystal engraving,paper/greeting card cutting etc.
6) metal cutting machine 150watt co2 laser sample:

Laser power | 150w | ||||
Material | Acrylic | MDF | Plywood | Stainless steel | Carbon steel |
Cutting thickness | 30mm | 10mm | 18mm | 1.5mm | 1.5mm |
Material | Cutting thickness | Cutting speed (mm/min) |
Stainless steel | 0.5mm | 2700 |
1mm | 1800 | |
1.5mm | 1000-1200 | |
Carbon steel
| 0.5mm | 3000 |
1mm | 1800 | |
1.5mm | 1000-1200 | |
Acrylic | 10mm | 300 |
20mm | 90-120 | |
MDF | 10mm | 300-400 |
8)Our services of metal cutting machine 150watt co2 laser
1)Guarantee for 24 months except comsumable parts .Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2)when receiving the your money, we will prepare machine for you,it will spend 2-3days, to get the shipping pictures for you.
3)24-hour technical support Internet or by Telephone, free instructions and Problem solving.
4)Free installation and fully test before sending and free training for operators
9)Packaging and shipping of metal cutting machine 150watt co2 laser
1. Packing wooden case is after fumigation treatment. Needn’t timber inspection,saving shipping time.
2.All the spare parts of the machine were covered by some soft materials,mainly
Avoiding all damages that could happen in the delivery process.Then we’ll covered plastic wrap out it tightly,make sure intact of the covered soft materials,also avoiding Waterproof and rust proof.
3.The outmost is wooden case with fixed formwork.
4.The bottom of the wooden case has firm iron jack,convenient to Handling and transport.
cnc laser cutting machine
10)Factory and certification:
