Specifications
pcb printing machine 1)wholly aluminum cast frame 2)advanced designation and device 3)high accuracy 4)CE BV ISO1.Characteristic:
1.high accuracy ball bearing guide screw of taiwan,minimize the slit.
2.imported linear rail,self lubricating glide.
3.our routers have the features of recarving after stop and the power failure may be restored.
4.unique preservation way of the zero point.
5.use for long time and no distortion.
6.this type is also suitable for advertisement.
2.Performance parameter:
XYZ working area |
300*300*80mm |
XYZ travel positioning accuracy |
±0.05mm |
XYZ repositioning positioning accury |
±0.05mm |
lathe structure |
Cast aluminum |
guide rails |
round(square for optional) linear guide rails |
drive system X Y Z axis |
Ball screw transmission |
Spindle power |
800w water cooling spindle |
Working speed |
8m/min |
Spindle speed |
24000rmp/min |
work mode |
Stepper |
Working voltage |
AC220V 50/60HZ |
Command language |
G code,*uoo,*mmg,*plt |
Interface |
USB |
X-Y resolution |
0.025mm |
Software environment |
Ucancam type3 artcam |
Weight |
100kg |
3.Applicable area:
materials:microlite,nature granite,stone,marble,bowlder,rostone,glass,aluminum,iron,and wood etc.
Industry:stone prcessing,metal processing,mould making,sign making and so on.
4.Samples:
5.Our company:
Our company was established in 1994,we are manufacture and specilized in laser engraving and cutting machine,cnc router,plasma cutting machine and cutting plotter.From 2007,we have expanded our bussiness to worldwide.In the past 6 years,so many clients all over the world cooperated with us and built a good business realtions.We have much experiece on our after-sale problems.
6.The package and transportation:
we have been cooperating with several big transport agents and shipping companies for long terms,and the goods are packed with standard wooden case for export,it can be transported to you safety as oon as possible.
7.Guarantee&Aftersales service:
1 Guarantee for one year.
2 Technical support in 24 hours,help slove the relative questions in time.
3 User-friendly English manual for machine usage and maintance.
