Help CenterXj1212 Used Foam Cutting Hot Sale Mini Cnc Router Wood
Related Products
-
Lowest Price Galvanometer Diode Laser Marking Machine With CE&BV&ISOUS$ 2,000 - 10,000MOQ: 1 Set -
Semiconductor Side-pumped Laser Marking MachineUS$ 1,000 - 5,000MOQ: 1 Set
-
Hot Sale High Precision and Professional Multi-head Cnc Router China JinanUS$ 1,999 - 19,999MOQ: 1 Set
-
NEW CNC ROUTER FOR WOODWORKING CHINA JINAN XYZ-TECHUS$ 1,000 - 10,000MOQ: 1 Set
-
CHINA JINAN XJ-1212 Wooding Mould Cnc Router With CEUS$ 2,000 - 5,000MOQ: 1 Set
Specifications
xj1212 used foam cutting hot sale mini cnc router wood:1.high accuracy and working speed.2.It has CE certificatexj1212 used foam cutting hot sale mini cnc router wood
1.Integrated optimized design and high quality aluminum alloy frame, which ensure solid and warp-proof.
2.Unspace ball screw using Germany technology, aligning with high power driving motor and imported coupling, that make movement stable and work precise in a long time.
3.High power non-brushing motor, N-CVT, power saving, lower noise, strong cutting capability, which ensure a batch process for a long time.
4.Restoring function enable the machine stop running automatically while power off, and automatically restart to work when power on, and also can store the break point from which for later operation to start, with the function of anticipating working time , auto tool sensor, the rotating speed and processing depth could be adjusted optional.
Application: sign board process, mould, and bronzing mould, motor, trim injection mould, shoe mould, badge, pattren mould, art crave, dial, font mould, mold, sign and label etc.
Model | XJ1212 | |
Working Area | 1200×1200×100mm | |
Spindle Motor | 1.5kw/2.2kwInverter-driven spindle motor cooled by water (or air for option) | |
Working Mode | Stepper motor | |
Control System | DSP off-line control panel with USB interface(128MB) or PCIMC control system | |
Drive Mechanism | Gear-wheel on x,y axis | |
Table Surface | Vacuum table o& T-slot extrusions | |
Frame | wholly steel structure | |
Motion Positioning Accuracy | ±0.03/300mm | |
Repositioning Accuracy | ±0.05mm | |
Max Motion Speed | 50,000mm/min | |
Max Engraving Speed | 30,000mm/min | |
Rotating Speed of Spindle | 2,4000rpm | |
Z-axis setting | Auto Z origin tool high sensor | |
Dictate Formate | G code, *.u00, *.mmg, *.plt | |
Operating Voltage | 220v | |
Software | Type3 copy/original with Dongle or Wentai (ArtCUT), ArtCAM software | |
Packing Size | 1850*1710*1300mm | |
Lubrication System | Oil lubrication system | |
Net weight/ Gross Weight | 370kg/ 420kg | |
Noise Level | Racing | LAeep dB(A)72±1 |
Engraving | LAeep dB(A)80±2 | |
Engraving Peak | LAeep dB(C)95 | |
Optional Parts | Dust Collecting System 2.2kw/3kw | |
Vacuum Table with Air Pump (For XJ1224,1325) | ||
Mist Sprayer and flume | ||
Rotary device with Dia100mm/200mm | ||
DSP System w/Portable Control Pad (128MB) | ||
we have been cooperating with several big transport agents and shipping companies for long terms,
and the goods are packed with standard wooden case for export,it can be transported to you safety
as oon as possible.
1.Guarantee&Aftersales service:
a)guarantee for one year
b)24 hour technical support by email or calling
c)User-friendly english manual for machine using and maintaining
2.Free technician training for big buyers
Rationalization of pre-sales consulting
Our company was established in 1994,we are manufacturer and specialize in laser engraving and cutting
machine,CNC router,plasma cutting machine and cutting plotter.From 2007,we have expanded our business
to worldwide.In the past 7 years,so many clients all over the world cooperated with us and built a good business
relations. We have much experience on our after-sale problems.
