XJ3030 mini CNC Router (CE)

FOB Price

US$ 1,000 - 2,000 / Set

1 Set(Min. Order)

Port QINGDAO
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	XYZ-TECH
Model Number	3030		Condition	New

Product Description

Specifications

Mini CNC Router:
Special feature of Carving with high precision
desktop,smart working job
Movable working table

Multifunctional mini cnc router with CE certificate

Technical Specification

model		XJ3030
working range		30030080mm/150mm as required
working speed		4,200m/min
accuracy		0.0245mm
spindle		0.8/1.5/2.2kw 24000rpm/min
working voltage		110v/220v 50HZ/60HZ
cutting tool		3.175mm,4mm, 6mm
software		type3 copy software /Artcam/CAXA
weight		100kg
mechanical drive		ball bearing guide screw

Machine body: Whole cast by aluminum
Working dimensions(X x Y x Z): 300 x 300 x 80mm or longer
Max. Feeding height: 120mm or more
Cuting thickness of material: <20mm
Driver type: Stepper motor
Blade diameter: 3.175mm,4mm,6mm (optional)
Control system: Weihong PC-control(NC-STUDIO) or DSP off-line control(USB)
Running circumstance temperature: 0 - 45
Relative humidity: 30% - 75%

Spindle Motor: 800w water-cooled

Drive mechanism: Stepper motor with leadshine drive

Drive mechanism: German imported ballscrew

Resolution: 0.01mm

Z high setting: auto Z tool sensor

Max motion Speed: 4,200mm/min

Max engraving speed: 3,000mm/min

Rotating Speed of Spindle: 0~2,4000rpm

Dictate Formate: G code

Operating voltage: AC110V/220V 50Hz/60Hz

Proper Features

Humanlistic design,the machine can be disassembled,so it is easilly transported.
Applicablematerial:microlite,naturalgranite,seeingstone,marble,bowlder,bluestone ,rostone,glass,aluminum,iron,plastic and wood etc.
Applicable industry: mould and label signage making stone &metal industry.
