Perfect Laser PE-W450II 450w Fiber Stainless Steel Laser Welding Machine
Application of Stainless Steel Laser Welding Machine:
Advertising letter laser welding machine is used for making a variety of stainless steel letter, LED luminous characters, LOGO, signs and other fast welding.
Features of Stainless Steel Laser Welding Machine:
1.Laser head can electrically move back and forth, up and down, left and right and rotate 360 degree.
2. Heat affected zone is small. The work piece surface will not deformed.
3. For letters in the advertising industry, there is specially lengthened optical path and th elescopic scope can be added to 800mm.
4. There is no raised spot after welding. No requirement of polishing process. Saving time and labor. The appearance is beautiful and tight.
5. There is optional CCD monitor. The welding effect is more clear and intuitive.
6. The specially designed long focal distance lens F=200mm to meet the demand for ultra-high font welding.
Technical data of Stainless Steel Laser Welding Machine:
PE-W450II Stainless Steel Laser Welding Machine | |
Max laser power | 450W |
Laser wave-length | 1064nm |
Single power energy | 90J |
Welding depth | 0.1-1.2mm |
Pulse width | 0.3-20ms |
Welding frequency | 0.5-40HZ |
Adjustable facular size | 0.2-2mm |
Power consumed | ≤9KW |
Electrical source | 220V±10%/50Hz/40A |
Standard worktable | 800*1000mm |
Positioning | Optional CCD + Red Dot |
2-linertary | 200mm |
Mobile level | 200mm |
double optic path metal letter laser welding machine products details:
Company information:
We, Perfect Laser located in Wuhan China, 21 years history in laser filed, with TUV/ISO/CE/FDA. we, provided with more than 200 different models for your to choose, It has been exported top to more than 180 countries and areas.
After- Sale Service:
1> All of our machine will be full-checked by our quality control department before the shipment. We make sure that customers
will be get good products from us. and all of our machine with a 12 months quality guarantee period.
2> We will enclose an "Instruction Book", "Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the
customer.
3> We will offer plenty of online supports, by email, video, telephone and fax.
4> Our engineer can make a door-to-door instruction training service.
Please advise us the following information, then we can recommend you the most suitable model, right now, don't hesitate to contact –China Perfect Laser !
- The exact material you want to cut? (Stainless steel, carbon steel, mild steel, aluminum, folded aluminum etc.)
- The depth on above materials?(max thickness, 0.5 mm, 0.6mm, 0.8 mm,1mm....)
- In order to recommend suitable machine to you, may i know are you enduser or reseller?
Need more information please feel free to contact us-Perfect Laser!---Right Now!!
