Areas of applications:
Detection of mobile phones
Searching of Improvised Explosive Devices (electronic control systems of IEDs) at background of complex man-made interference from urban constructions
Detection of concealed electronic devices during TCSM operations
Features:
√ New non-linear junction detector NR-SOUND, ensuring sensitivity not worse than minus 140 dBm
√ Range of detection is comparable to the nonlinear detector NR900EK "Eagle".
√ A non-trivial solution for the receiving tract provides for the possibility of fine structure analysis of the reflected signal.
√ For the first time the possibility of identifying and selecting of active electronic targets against a background of interfering noise generated by other electronic devices is realized.
Email:jingdun2016@foxmail.com
| Characteristics: | |
| Target detection range. Standard imitator - test unit (maximum probing signal output & maximum receiver sensitivity). | not less than 1 meter. |
| The average power of probing signal in the search mode | not more than 400 mW |
| Sensitivity | not worse than -140 dBm |
|
Probing signal level
-max
-mid -min |
0 dB
-6 dB -12 dB |
| Receiver input signal attenuation | 10 dB, 20 dB, 30 dB, 40 dB |
|
Received signal level indication
-visual
-audio |
LED display
Headphones |
| Power supply | 2 x ‘Soshine’ 18650 Li-ion rechargeable cells 2800mAh, 3.7V |
| Operational condition: Operating temperature Storage and shipping temperature Relative humidity (under +25°С) |
+5°С … +40°С
Minus 20°С … +50°С 93±3 % |
| Continuous operation time with two sets of fully charged cells: -Searchnig mode -Listening mode |
not less 8 h
not less 1 h |
| Weight: Device in a ready for operation state Main unit ‘Pistol-grip’ control unit ‘Rifle-buttstock’ control unit Complete set in a standard packing |
1.4 kg
1.0 kg
0.4 kg.
1.2 kg.
7.5 kg
|
