BDF drinking underground water storage tank with new technology
Product Description
BDF water tank panel is a kind of compound material that interior is stainless steel material, exterior
is hot dip galvanized sheet material. The biggest advantage of BDF tank is that it can be used as underground
water tank. Underground water tank can be used in many engineering, deep buried depth, sometimes up
to 4 ~ 5 meters, ordinary water tank can't be buried so deeply in underground, because of overwhelming
of the underground soil pressure, and ground water tank is specially to solve this problem as the research
and development, able to withstand a lot of soil pressure, even after the buried soil and tank top reinforcement
processing can withstand the pressure of a small car. Now the rain water recycling system is inevitable to use
underground water tank, underground water tank in this field is still very popular.
BDF tank can also contain drinking water on the ground, because of its internal stainless steel fittings,
drinking water is completely harmless to the human body, BDF tank can be universal tank on the
ground and underground.
Characteristics
1. BDF panel combines the advantages of stainless steel panel and hot dip galvanized panel,
compared with the stainless steel tank in screw connection to reduce the cost, compared with
galvanized steel water tank to ensure the water quality.Not only that, the BDF plate also has
more excellent mechanical properties, higher strength, toughness is greater.BDF tank receives
the market consensus, gradually become an ideal storage solution, is widely used for buried
large tank.
2.Tank sealing using specially designed styling products sealing tape and the sealing tape is
nontoxic, water resistant and oxidation resistantsealing properties as well as good. Service
life of up to 50 years.
3. Health conditions are good. In contact with water, molded parts made of high quality stainless steel plates.
4. High structural strength. Reinforced molded parts made of galvanized steel sheet forming.
5.Serviceable, strong corrosion resistance, long service life. Module made by module compound,
and using the screws installation.Avoid the disadvantages of corrosion of welded stainless steel
chrome badly under high temperature.
6. Water tank mould easilydisassemble. After demolition ,mould still can be arbitrary
combinations.
7.environmental protection, energy saving, without secondary pollution.
8.Appearance, color diversity. Color can be selected according to userrequirements for any
tank appearance.
Instructions
1.Please provide water tank’s size, position and diameter of pipe. Tank can matching supply.
2.When the provided pipe position is on the slab joint,we will adjust it and no change in pipe’s diameter.
3.Body load of water tank is base on the approved by structure design personnel.
4.When water testing, prevent the debris into box.
5.Regular cleaning
Assembling and check
1.There needs to Keep a maintenance channel which width no less than 700mm betwteen the
vertical wall and water tank, and between horizontal wall and water tank body no less than
500mm.
2.When construction, finish concrete foundation first, make sure all slab joints and the surrounding of the water tank is located on thesupport.
3.When finished assembled, turn off the The outlet pipe and a drain pipe first, then turn on theinlet pipe, as water as examine to fill with water, no leakage in 24 hours is qualified.
Accessaries
Certification
Packing & Delivery
FAQ
1.What's the guarantee, in case the water tank breaks down?
The water tank has one year s guarantee. If it breaks down, generally speaking, our technician will figure out
what the problem may be, according to client s feedback. Parts will be replaced for free if the problems are
caused by quality fault.
2.How about the documents after shipment?
After shipment, we will send all original documents to you by DHL, including Packing List,
Commercial Invoice, B/L, and other certificates as required by clients.
3.How long is the delivery time?
For standard water tank less than 100m3, it would be 7-10 days; For non-standard water tank and customized water tank according to client s specific requirements,
it would be 15 to 30 days.
4.How's the payment?
Telegraphic Transfer(T/T).
5.Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
For EXW price, clients need to arrange shipment by themselves or their agents.
6.How is the packing?
Solid Seaworthy plywood Box Package with Steel Belt
Save space as much as possible for container loading
Company show
Company introduction
Dezhou Huili tank Co. Ltd., is a professional production enterprise specializing in the
production and design of the water tank.
Company tenets: quality first, customer first and best credibility! The same price with
best quality, the same quality with highest reputation!
The company has a professional after-sale service institution, each service branch are
provided with a fixed installation and after sale service personnel to ensure the user
to get a response from us in the first time
