Huili latest buried underground BDF water storage tank made in china
buried underground water tank
Keywords to search Huili water tank:
SMC/FRP/GRP water tank
Stainless steel water tank
Enameled water tank
Hot dip galvanised water tank
BDF/CSB water tank
All of water tank can add thermal insulation layer and reinforcement outside
Product Description
The BDF is the latest product of our company. The board is the center of the technical innovation, which inside use the SS304 and outside use the hot dip galvanized steel.
This is perfect combination of the advantage of the stainless steel water tank and hot dip
galvanized steel water tank.
Product Name |
BDF water tank |
Process technique |
Stamping forming process |
Raw material |
SUS304 inside hot dip galvanizing outside |
Accessories |
SUS304;hot dip galvanizing steel |
Foundation |
Concrete base |
Bottom base |
Channel steel |
Panel size |
1*1m,1*0.5m,0.5*0.5m |
Panel thickness |
2.8mm,3.3mm |
Working time |
More than 20 years |
Volume |
0.125~5000CBM |
Application
1. Construction & fire-fighting water supply
2. Water storage pool
3.Water supply for living and production of industry, mining and enterprise
4.Water circulation system, chilling water and hot water supply system
Instructions
1.Please provide water tank’s size, position and diameter of pipe. Tank can matching supply.
2.When the provided pipe position is on the slab joint,we will adjust it and no change in pipe’s diameter
3.Body load of water tank is base on the approved by structure design personnel.
4.When water testing, prevent the debris into box.
5.Regular cleaning
Assembling and check
1.There needs to Keep a maintenance channel which width no less than 700mm betwteen the
vertical wall and water tank, and between horizontal wall and water tank body no less than
500mm.
2.When construction, finish concrete foundation first, make sure all slab joints and the
surrounding of the water tank is located on the support.
3.When finished assembled, turn off the The outlet pipe and a drain pipe first, then turn on
theinlet pipe, as water as examine to fill with water, no leakage in 24 hours is qualified.
Characteristics
1. BDF panel combines the advantages of stainless steel panel and hot dip galvanized panel,
compared with the stainless steel tank in screw connection to reduce the cost, compared with
galvanized steel water tank to ensure the water quality.Not only that, the BDF plate also has
more excellent mechanical properties, higher strength, toughness is greater.BDF tank receives
the market consensus, gradually become an ideal storage solution, is widely used for buried
large tank.
2.Tank sealing using specially designed styling products sealing tape and the sealing tape is
nontoxic, water resistant and oxidation resistant sealing properties as well as good. Service
life of up to 50 years.
3. Health conditions are good. In contact with water, molded parts made of high quality stainless
steel plates.
4. High structural strength. Reinforced molded parts made of galvanized steel sheet forming.
5.Serviceable, strong corrosion resistance, long service life. Module made by module compound,
and using the screws installation.Avoid the disadvantages of corrosion of welded stainlesssteel
chrome badly under high temperature.
6. Water tank mould easilydisassemble. After demolition ,mould still can be arbitrary combinations.
7.environmental protection, energy saving, without secondary pollution.
8.Appearance, color diversity. Color can be selected according to userrequirements for any
tank appearance.
Accessaries
Our services
1.Professional water tank manufacturer.Customized design is available, OEM and ODM are welcomed.
2.High quality,reasonable&competitive price.High speed forwarder services.
3.Prompt answer on Trademanager and Inquiry,will not delay 24 hours.
Certification
Packing & Delivery
Company show
Dezhou Huili tank Co. Ltd., is a professional production enterprise specializing in the
production and design of the water tank.
Company tenets: quality first, customer first and best credibility! The same price with best
quality, the same quality with highest reputation!
The company has a professional after-sale service institution, each service branch are
provided with a fixed installation and after sale service personnel to ensure the user to get a
response from us in the first time.
