2015 latest Huili BDF underground water tank
What‘s the BDF water tank?
Fabricated BDF water tank is assembled together by BDF single plate,seal mateials,metal compents and piping system.
Product Name |
BDF water tank |
Process technique |
Stamping forming process |
Raw material |
SUS304 inside hot dip galvanizing outside |
Accessories |
SUS304;hot dip galvanizing steel |
Foundation |
Concrete base |
Bottom base |
Channel steel |
Panel size |
1*1m,1*0.5m,0.5*0.5m |
Panel thickness |
2.8mm,3.3mm |
Working time |
More than 20 years |
Volume |
0.125~5000CBM |
Application
1. Construction & fire-fighting water supply
2. Water storage pool
3.Water supply for living and production of industry, mining and enterprise
4. Water circulation system, chilling water and hot water supply system
Characteristics
1. BDF panel combines the advantages of stainless steel panel and hot dip galvanized
panel, compared with the stainless steel tank in screw connection to reduce the cost, compared
with galvanized steel water tank to ensure the water quality.Not only that, the BDF plate also
has more excellent mechanical properties, higher strength, toughness is greater.
BDF tank receives the market consensus, gradually become an ideal storage solution, is
widely used for buried large tank.
2.Tank sealing using specially designed styling products sealing tape and the sealing tape is
nontoxic, water resistant and oxidation resistant sealing properties as well as good. Service
life of up to 50 years.
3. Health conditions are good. In contact with water, molded parts made of high quality
stainless steel plates.
4. High structural strength. Reinforced molded parts made of galvanized steel sheet forming.
5.Serviceable, strong corrosion resistance, long servicelife. Module made by module
compound, and using the screws installation. Avoid the disadvantages of corrosion of welded
stainless steel chrome badly under high temperature.
6. Water tank mould easily disassemble. After demolition ,mould still can be
arbitrary combinations.
7.environmental protection, energysaving, without secondary pollution.
8.Appearance, color diversity. Color canbe selected according to user requirements for any
tank appearance.
Assembling and check
1.There needs to Keep a maintenance channel which width no less than 700mm betwteen the
vertical wall and water tank, and between horizontal wall and water tank body no less than
500mm.
2.When construction, finish concrete foundation first, make sure all slab joints and the surrounding
of the water tank is located on the support
3.When finished assembled, turn off the The outlet pipe and adrain pipe first, then turn on the inlet pipe,
as water as examine to fill with water, no leakage in 24 hours is qualified.
Accessaries
Our services
1. Professional water tank manufacturer.Customized design is available, OEM and ODM are welcomed.
2. High quality, reasonable&competitive price. High speed forwarder services.
3. Prompt answer on Trademanager and Inquiry, will not delay 24 hours.
Certification
Packing & Delivery
Company show
Dezhou Huili tank Co. Ltd., is a professional production enterprise specializing in the production
and design of the water tank.
Company's products include: fiber glass reinforced plastic water tank, stainless steel water tank,
enamel steel water tank, hot dip galvanized steel water tank, gush paint steel water tank and
underground water tank.
Company tenets: quality first, customer first and best credibility! The same price with best quality,
the same quality with highest reputation!
The company has a professional after sale service institution, each service branch are provided
with a fixed installation and after sale service personnel to ensure the user to get a response from us in the
first time.
