Test Sieves 4 Layers for Coke, Mechanical Industrial Sieve Screen

Test Sieves 4 Layers for Coke, Mechanical Industrial Sieve Screen photo-1
Test Sieves 4 Layers for Coke, Mechanical Industrial Sieve Screen photo-2
US$ 27,500 - 29,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Linear
Application:
Ore
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Type Linear
Application Ore
Place of Origin Zhejiang, China
Brand Name HONGXING
Model Number HXAG-2005
Voltage 380V
Power(W) 2.2kw
Dimension(L*W*H) 3200*1850*1700mm
Weight 600kg
Certification ISO9001
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Test sieves 4 layers for coke, mechanical industrial sieve screen

Product Description
Product Description

Screen surface specifications (mm)

80×80,60×60,40×40,25×25



Sieve plate installation dimensions (mm)

1090×890

The amplitude (mm)

3-6

The motor (KW)

2.2

Voltage (V)

380

The total weight (kg)

600

Equipment overall dimensions (mm)

3200×1850×1700
Details
Details

Test sieves 4 layers for coke, mechanical industrial sieve screenTest sieves 4 layers for coke, mechanical industrial sieve screen

Coke sieve grouped into mechanical screen conforms to the national standard GB/T2005-1994. This equipment improve the screening effect, reduce operating labor intensity and is suitable for metallurgical coke formed at all levels (80-40-60 mm, 60, 40 mm, 25 mm) and the determination of the content of coke, is to replace hand screen, improve the coke content detection accuracy, eliminate the human error at the end of the ideal equipment. This mechanical screen structure is compact, easy to operate, reliable operation. It has set up a file in the GB/T2005-1994 technical standard.



HXAG - 2005 coke sieve grouped into mechanical screen has a hopper, spring pillar, frame body of vibrator, motor, base and motivation, there are four layers and tilted 11.5 degrees, can make the coke along the inclined plane with vibration move down to result the good sieving effect.
