■ Specifications
►Application
The H07RN-F is designed primarily as a trailing cable for use in the supply of energy for portable or mobile equipment. Heavy duty Harmonized cables are not only robust but also extremely flexible. PCP neoprene is also oil and flame retardant. Typical applications of the H07RN-F cable include transformers, pumps, welders, grinders, temporary lighting cable and feed cables to heavy mobile equipment.
►Technical Information
Standards: BS7919, CENELEC HD22.4 S4
Conductor: Class 5 flexible plain copper to BS EN 60228:2005 (previously BS6360)
Insulation: EPR (Ethylene Propylene Rubber) Type EI4 to BS7655
Sheath: PCP (Polychloroprene) Type EM2 to BS7655
Sheath Colour: Black
Voltage Rating: 450/750V
Number of cores: 1,2,3,3+1,4,5
Cross Sectional Area:1.5sqmm up to 400sqmm
Temperature Rating: Conductor operating temperature -30°C to +60°C (85°C max)
Minimum Bending Radius:
Up to 25mm²: 6 x overall diameter
Above 25mm²: 8 x overall diameter
►Core Identification
2 Cores: Blue, Brown
3 Cores: Green/Yellow, Blue, Brown
4 Cores: Green/Yellow, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
6 Cores and above: Black with White numerals, Green/Yellow
■ Technical Data
No. of Cores x Normal | Normal Diameter | Normal Thickness | Normal Thickness of Jacket(mm)
| Over Diameter | Max Conductor Resistance |
2x1.0 | 0.2 | 0.8 | 1.3 | 8.3±0.5 | 17 |
2x1.5 | 0.253 | 0.8 | 1.5 | 9.3±0.5 | 21 |
2x2.5 | 0.253 | 0.9 | 1.7 | 11.2±0.5 | 30 |
2x4 | 0.3 | 1 | 1.8 | 12.8±0.5 | 39 |
2x6 | 0.3 | 1 | 12 | 14.4±0.5 | 51 |
3G1.0 | 0.2 | 0.8 | 1.4 | 9.0±0.5 | 12 |
3G1.5 | 0.253 | 0.8 | 1.6 | 10.1±0.5 | 18 |
3G2.5 | 0.253 | 0.9 | 1.8 | 12.1±0.5 | 26 |
3G4 | 0.3 | 1 | 1.9 | 13.9±0.5 | 34 |
3G6 | 0.3 | 1 | 2.1 | 15.4±0.5 | 43 |
4G1.0 | 0.2 | 0.8 | 1.5 | 9.9±0.5 | 14 |
4G1.5 | 0.253 | 0.8 | 1.7 | 11.1±0.5 | 18 |
4G2.5 | 0.253 | 0.9 | 1.9 | 13.3±0.5 | 27 |
4G4 | 0.3 | 1 | 2 | 15.2±0.5 | 34 |
4G6 | 0.3 | 1 | 2.3 | 17.2±0.5 | 44 |
5G1.0 | 0.2 | 0.8 | 1.6 | 11.0±0.5 | 14 |
5G1.5 | 0.253 | 0.8 | 1.8 | 12.2±0.5 | 18 |
5G2.5 | 0.253 | 0.9 | 2 | 14.6±0.5 | 27 |
5G4 | 0.3 | 1 | 2.2 | 16.9±0.5 | 34 |
5G6 | 0.3 | 1 | 2.5 | 19.1±0.5 | 44 |
