2014 New Artificial Sand Making Machine Supplier
- 50 Set / Sets per Month
- Qingdao Shanghai etc.
- T/T
- Mining Stone Crushing Machine Silica Quartz Sand Making Production Line
- High Efficiency Stone Fine Crusher 5X Series Sand Making Machine
- High Efficient Artificial Building VSI Crusher Sand Making Machine Equipment
- Automatic Zero Discharge Concrete Recycling System
- Concrete Batching Plant Parts
- Concrete Recycling Machine
Product Details
Condition: | New | Production Capacity: | 150-190t/h | Place of Origin: | Henan, China |
Brand Name: | UNIQUE | Model Number: | VSI9526 | Voltage: | 380v |
Power(W): | 264 KW | Dimension(L*W*H): | 4560*2447*2778mm | Weight: | 17.8t |
Certification: | ISO9001:2000,CE | Warranty: | More than 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
1.The motor can be heated automatically in winter2. Unique vibrating alarm device
3. Special feeding structure
4.Low price
VSI Artificial Sand Making Machine Supplier
Introduction of our VSI artificial Sand Making Machine
VSI Sand Making Machine is widely used in fine crushing and rough grinding of metal, mineral, building aggregate, concrete, anti-fire material, glass raw material, manufactured sand and all kinds of metallurgical slug. It is also can utilized in shaping of high rank road surface. Compared with other kind of crusher, it is more advanced in intermediate hard, extra hard and abrasive material. Sand Making Machine is improved on the basis of Germany high technology, which is highly-efficient and superior in performance. The Unique VSI Crusher (sand making machine) is widely used to produce sand and stone for highway, high-speed railway, city project, hydropower dam constructions, and concrete mixing plant, and it’s also widely used in sand making and stone reshaping industry.
Features and Benefits of Our Sand Making Machine
1. The oil needed is supplied by two oil pumps, and the machine stops automatically if there is no oil; the motor can be heated automatically in winter to ensure the normal working of the machine.
2. Hydraulic lifting system to check and replace the spare parts, thus it’s very easy and simple to maintain.
3. The bearing is of SKF and TIMKEN brand to ensure the normal working of the machine.
4. Unique vibrating alarm device: if the machine works abnormally, the alarm will sound to stop the machine, thus protecting the whole machine.
5. Special feeding structure; rock on rock, and rock on iron to make the stones crushed and reshaped.
6. Unique dustproof seal system to prevent the dust getting into the spare parts.
7. Unique design of material bumping angle reduces the friction between raw material and spare parts, extending the working life of spare parts and cut the cost.
8. Low price
After-Sale Service of Our Sand Making Machine
Erection and Commissioning
Operator Training
Spare Parts Supply
Warranty Terms: More than 12 months
Delivery Time: 20~30 days after receiving advanced payment .
Products Certificate: TUVRheinland CE , ISO9001:2000
Working Principle of Our Sand Making Machine
- Central feeding:Raw materials fall down into the feeding hopper, then enters the impellor through central entrance inlet, thus the material being accelerated by the high-speed impellor and being thrown out at the speed of 60-75m/s. It is crushed when hitting the impact plate, and the end products comes out from the discharging outlet.
- Ring feeding:Raw materials fall down into the feeding hopper, and the materials are divided into two parts by a special plate. Some materials enter the impellor through the center of the plate and the other part of materials falls down from outside of the plate. The materials thrown out earlier crush the materials down from outside, thus the materials crushed and re-crushed.
The Application of Sand Maker
1. River pebbles, rocks (limestone, granite, basalt, diabase, and esite), ore tailings, the artificial sand stone chips.
2. Production of construction aggregate, Highway fabric, cushion material, asphalt concrete and cement concrete aggregate.
3. Production of water conservancy and hydropower engineering, highway, highways, high-speed rail passenger line, bridges, airport runways, municipal engineering, high-rise building mechanisms sand and stone shaping.
4. Material crushing grinding of the mining areas of front-end crushing process, building materials, metallurgy, chemical, mining, refractory, cement, abrasive industry.
5. High abrasive and secondary disintegration broken, thermal power, metallurgy industry, in addition to sulfur, slag, construction waste crushing and other environmental projects.
6. Glass, quartz sand and other high purity materials production
Specification of Our VSISand Making Machine(Vertical Shaft Imapct Crusher) |
Model | Capacity(t/h) | Best feed size(mm) | Rototion speed(r/min) | Double motor power(kw) | Demension(mm) | Weight(t) | Power supplier | ||
feed both at center and at sides | Feed at center | Soft material | Hard material | ||||||
VSI-7611 | 120-180 | 60-90 | 35 | 30 | 1700-1890 | 110 | 3700*2150*2100 | 11.8 | 380V50HZ |
VSI-8518 | 200-260 | 100-130 | 40 | 35 | 1520-1690 | 180 | 4140*2280*2425 | 14.5 | |
VSI-9526 | 300-380 | 150-190 | 45 | 40 | 1360-1510 | 264 | 4560*2447*2778 | 17.8 | |
VSI-1140 | 450-520 | 220-260 | 50 | 45 | 1180-1310 | 400 | 5000*2700*3300 | 25.6 |
OUR PRODUCT SCOPE: |
Mobile Crusher: portable jaw crusher, portable impact crusher, portable cone crusher, portable construction waste crushing plant
Stone Crusher: jaw crusher, impact crusher, Symons cone crusher, spring cone crusher, sand making machine, hammer crusher, ball mill etc.
Auxiliary equipment: vibrating feeder, vibrating screen, belt conveyor, crawler rock drill
More information about our Sand Making Machine or other machine, please feel free to contact with us by phone or e-mail at any time, we will try our best to cooperate with you!
