China PL vertical shaft impact crusher/sand making machine for sale

Specifications

Vertical shaft impact crusher/sand making machine
1.Simple structure,low operating cost
2.Fine and coarse crushing function

China PL vertical shaft impact crusher/sand making machine for sale

1. Introduction of our Sand Making Machine

     Sand Making Machine is widely used in fine crushing and rough grinding of metal, mineral, building aggregate, concrete, anti-fire material, glass raw material, manufactured sand and all kinds of metallurgical slug. It is also can utilized in shaping of high rank road surface. Compared with other kind of crusher, it is more advanced in intermediate hard, extra hard and abrasive material

2.Features and Benefits of sand making machine

1. Simple structure , lower operation cost
2.  Cubic type , final product size: less than 5mm (30%~60%)
3. Working noise is less than 75 decibels and dust pollution is little.
4. Slightly influenced by the humidity of material, and the max humidity is 8%.
5. More suitable for crushing mid-hardness materials and high-hardness materials.
6. Have fine an coarse crushing function, few impellor wear down, easy to be maintained

3.Working Principle of Our Sand Making Machine

Sand making machine, also named as “sand maker”, plays an important role in crushing minerals into pieces. This equipment has two types: rock-on-rock and rock-on-iron. Sand yield of “rock-on-iron” type is higher by 10-20% than that of “rock-on-rock” type.

4.Specification of our sand making machine (vertical shaft impact crusher)





Model	Max. Feed Size (mm)	Impeller Speed (r/min)	Capacity (t/h)	Power (kW)
PL700	45	1700-2000	30-60	75-90
PL800	55	1400-1620	50-90	110-150
PL900	65	1330-1530	80-150	180-264
PL1050	80	1200-1400	150-250	264-320
PL1250	100	1000-1100	250-500	440-500
PL1300	100	1000-1100	500-700	500-640



 5. Appearance of the sand making machine





Shipment & Service

After-Sale Service of sand making machine

Erection and Commissioning

Operator Training

Spare Parts Supply

Warranty Terms: More than 12 months

Delivery Time: 20~30 days after receiving advanced payment .

Products Certificate: TUVRheinland CE , ISO9001:2000
